Dumux::StaggeredFVElementGeometry< GG, false > Class Template Reference

Base class for the finite volume geometry vector for staggered models This locally builds up the sub control volumes and sub control volume faces for each element. Specialization for grid caching enabled. More...

#include <dumux/discretization/staggered/fvelementgeometry.hh>

Description

template<class GG>
class Dumux::StaggeredFVElementGeometry< GG, false >

Base class for the finite volume geometry vector for staggered models This locally builds up the sub control volumes and sub control volume faces for each element. Specialization for grid caching enabled.

Template Parameters

GG	the finite volume grid geometry type

Public Types
using	SubControlVolume = typename GG::SubControlVolume
	export type of subcontrol volume More...
using	SubControlVolumeFace = typename GG::SubControlVolumeFace
	export type of subcontrol volume face More...
using	GridGeometry = GG
	export type of finite volume grid geometry More...
using	FVGridGeometry = GridGeometry

Public Member Functions
template<class CellCenterOrFaceFVGridGeometry >
	StaggeredFVElementGeometry (const CellCenterOrFaceFVGridGeometry &gridGeometry)
	StaggeredFVElementGeometry (const GridGeometry &gridGeometry)
	Constructor. More...
const SubControlVolumeFace &	scvf (GridIndexType eIdx, LocalIndexType localScvfIdx) const
	Get a sub control volume face with an element index and a local scvf index. More...
const SubControlVolume &	scv (GridIndexType scvIdx) const
const SubControlVolumeFace &	scvf (GridIndexType scvfIdx) const
std::size_t	numScv () const
	number of sub control volumes in this fv element geometry More...
std::size_t	numScvf () const
	number of sub control volumes in this fv element geometry More...
void	bind (const Element &element)
void	bindElement (const Element &element)
	Binding of an element preparing the geometries only inside the element. More...
const GridGeometry &	fvGridGeometry () const
	The global finite volume geometry we are a restriction of. More...
const GridGeometry &	gridGeometry () const
bool	hasBoundaryScvf () const
	Returns whether one of the geometry's scvfs lies on a boundary. More...

Member Typedef Documentation

FVGridGeometry

template<class GG >

using Dumux::StaggeredFVElementGeometry< GG, false >::FVGridGeometry = GridGeometry

GridGeometry

template<class GG >

using Dumux::StaggeredFVElementGeometry< GG, false >::GridGeometry = GG

export type of finite volume grid geometry

SubControlVolume

template<class GG >

using Dumux::StaggeredFVElementGeometry< GG, false >::SubControlVolume = typename GG::SubControlVolume

export type of subcontrol volume

SubControlVolumeFace

template<class GG >

using Dumux::StaggeredFVElementGeometry< GG, false >::SubControlVolumeFace = typename GG::SubControlVolumeFace

export type of subcontrol volume face

Constructor & Destructor Documentation

StaggeredFVElementGeometry() [1/2]

template<class GG >

template<class CellCenterOrFaceFVGridGeometry >

Dumux::StaggeredFVElementGeometry< GG, false >::StaggeredFVElementGeometry ( const CellCenterOrFaceFVGridGeometry &  gridGeometry )

inline

Constructor getting a auxiliary cell center of face specific FvGridGeometry type. Needed for the multi-domain framework.

StaggeredFVElementGeometry() [2/2]

template<class GG >

Dumux::StaggeredFVElementGeometry< GG, false >::StaggeredFVElementGeometry ( const GridGeometry &  gridGeometry )

inline

Constructor.

Member Function Documentation

bind()

template<class GG >

void Dumux::StaggeredFVElementGeometry< GG, false >::bind ( const Element &  element )

inline

Binding of an element preparing the geometries of the whole stencil called by the local jacobian to prepare element assembly

bindElement()

template<class GG >

void Dumux::StaggeredFVElementGeometry< GG, false >::bindElement ( const Element &  element )

inline

Binding of an element preparing the geometries only inside the element.

fvGridGeometry()

template<class GG >

const GridGeometry & Dumux::StaggeredFVElementGeometry< GG, false >::fvGridGeometry ( ) const

inline

The global finite volume geometry we are a restriction of.

gridGeometry()

template<class GG >

const GridGeometry & Dumux::StaggeredFVElementGeometry< GG, false >::gridGeometry ( ) const

inline

hasBoundaryScvf()

template<class GG >

bool Dumux::StaggeredFVElementGeometry< GG, false >::hasBoundaryScvf ( ) const

inline

Returns whether one of the geometry's scvfs lies on a boundary.

numScv()

template<class GG >

std::size_t Dumux::StaggeredFVElementGeometry< GG, false >::numScv ( ) const

inline

number of sub control volumes in this fv element geometry

numScvf()

template<class GG >

std::size_t Dumux::StaggeredFVElementGeometry< GG, false >::numScvf ( ) const

inline

number of sub control volumes in this fv element geometry

scv()

template<class GG >

const SubControlVolume & Dumux::StaggeredFVElementGeometry< GG, false >::scv ( GridIndexType  scvIdx ) const

inline

Get an elment sub control volume with a global scv index We separate element and neighbor scvs to speed up mapping

scvf() [1/2]

template<class GG >

const SubControlVolumeFace & Dumux::StaggeredFVElementGeometry< GG, false >::scvf ( GridIndexType  eIdx, LocalIndexType  localScvfIdx  ) const

inline

Get a sub control volume face with an element index and a local scvf index.

scvf() [2/2]

template<class GG >

const SubControlVolumeFace & Dumux::StaggeredFVElementGeometry< GG, false >::scvf ( GridIndexType  scvfIdx ) const

inline

Get an element sub control volume face with a global scvf index We separate element and neighbor scvfs to speed up mapping

---

The documentation for this class was generated from the following file:

• discretization/staggered/fvelementgeometry.hh
