Dumux::BoxDfmDefaultScvGeometryTraits< GridView > Struct Template Reference

Default traits class to be used for the sub-control volumes for the box discrete fracture scheme. More...

#include <dumux/porousmediumflow/boxdfm/subcontrolvolume.hh>

Description

template<class GridView>
struct Dumux::BoxDfmDefaultScvGeometryTraits< GridView >

Default traits class to be used for the sub-control volumes for the box discrete fracture scheme.

Template Parameters
GVthe type of the grid view
Note
We define new traits for the box-dfm sub-control volume face as we use a different type of container for storing the scvf corners!

Classes

struct  ScvMLGTraits


Public Types

using Grid = typename GridView::Grid

using GridIndexType = typename Grid::LeafGridView::IndexSet::IndexType

using LocalIndexType = unsigned int

using Scalar = typename Grid::ctype

using Geometry = Dune::MultiLinearGeometry< Scalar, dim, dimWorld, ScvMLGTraits< Scalar > >

using CornerStorage = typename ScvMLGTraits< Scalar >::template CornerStorage< dim, dimWorld >::Type

using GlobalPosition = typename CornerStorage::value_type


Static Public Attributes

static const int dim = Grid::dimension

static const int dimWorld = Grid::dimensionworld


Member Typedef Documentation

◆ CornerStorage

template<class GridView >
using Dumux::BoxDfmDefaultScvGeometryTraits< GridView >::CornerStorage = typename ScvMLGTraits<Scalar>::template CornerStorage<dim, dimWorld>::Type

◆ Geometry

template<class GridView >
using Dumux::BoxDfmDefaultScvGeometryTraits< GridView >::Geometry = Dune::MultiLinearGeometry<Scalar, dim, dimWorld, ScvMLGTraits<Scalar> >

◆ GlobalPosition

template<class GridView >
using Dumux::BoxDfmDefaultScvGeometryTraits< GridView >::GlobalPosition = typename CornerStorage::value_type

◆ Grid

template<class GridView >
using Dumux::BoxDfmDefaultScvGeometryTraits< GridView >::Grid = typename GridView::Grid

◆ GridIndexType

template<class GridView >
using Dumux::BoxDfmDefaultScvGeometryTraits< GridView >::GridIndexType = typename Grid::LeafGridView::IndexSet::IndexType

◆ LocalIndexType

template<class GridView >
using Dumux::BoxDfmDefaultScvGeometryTraits< GridView >::LocalIndexType = unsigned int

◆ Scalar

template<class GridView >
using Dumux::BoxDfmDefaultScvGeometryTraits< GridView >::Scalar = typename Grid::ctype

Member Data Documentation

◆ dim

template<class GridView >
const int Dumux::BoxDfmDefaultScvGeometryTraits< GridView >::dim = Grid::dimension
static

◆ dimWorld

template<class GridView >
const int Dumux::BoxDfmDefaultScvGeometryTraits< GridView >::dimWorld = Grid::dimensionworld
static

The documentation for this struct was generated from the following file:
