Dumux::SolidSystems::InertSolidPhase< Scalar, ComponentT > Class Template Reference

A solid phase consisting of a single inert solid component. More...

#include <dumux/material/solidsystems/inertsolidphase.hh>

Description

template<class Scalar, class ComponentT>
class Dumux::SolidSystems::InertSolidPhase< Scalar, ComponentT >

A solid phase consisting of a single inert solid component.

Note

a solid is considered inert if it can't dissolve in a liquid and and can't increase its mass by precipitation from a fluid phase.

Public Types
using	Component = ComponentT

Static Public Member Functions
static std::string	componentName (int compIdx=0)
	A human readable name for the component. More...
static std::string	name ()
	A human readable name for the solid system. More...
static constexpr bool	isCompressible (int compIdx=0)
	Returns whether the phase is incompressible. More...
static constexpr bool	isInert ()
	Returns whether the component is inert (doesn't react) More...
static Scalar	molarMass (int compIdx=0)
	The molar mass in \(\mathrm{[kg/mol]}\) of the component. More...
static Scalar	density (Scalar temperature)
	The density \(\mathrm{[kg/m^3]}\) of the solid phase at a given pressure and temperature. More...
template<class SolidState >
static Scalar	density (const SolidState &solidState)
	The density \(\mathrm{[kg/m^3]}\) of the solid phase at a given pressure and temperature. More...
static Scalar	thermalConductivity (Scalar temperature)
	Thermal conductivity of the solid \(\mathrm{[W/(m K)]}\). More...
template<class SolidState >
static Scalar	thermalConductivity (const SolidState &solidState)
	Thermal conductivity of the solid \(\mathrm{[W/(m K)]}\). More...
static Scalar	heatCapacity (Scalar temperature)
	Specific isobaric heat capacity of the solid \(\mathrm{[J/(kg K)]}\). More...
template<class SolidState >
static Scalar	heatCapacity (const SolidState &solidState)
	Specific isobaric heat capacity of the solid \(\mathrm{[J/(kg K)]}\). More...

Static Public Attributes
static constexpr int	numComponents = 1
static constexpr int	numInertComponents = 1

Member Typedef Documentation

Component

template<class Scalar , class ComponentT >

using Dumux::SolidSystems::InertSolidPhase< Scalar, ComponentT >::Component = ComponentT

Member Function Documentation

componentName()

template<class Scalar , class ComponentT >

static std::string Dumux::SolidSystems::InertSolidPhase< Scalar, ComponentT >::componentName ( int  compIdx = 0 )

inlinestatic

A human readable name for the component.

Parameters

compIdx

The index of the component to consider

density() [1/2]

template<class Scalar , class ComponentT >

template<class SolidState >

static Scalar Dumux::SolidSystems::InertSolidPhase< Scalar, ComponentT >::density ( const SolidState &  solidState )

inlinestatic

The density \(\mathrm{[kg/m^3]}\) of the solid phase at a given pressure and temperature.

density() [2/2]

template<class Scalar , class ComponentT >

static Scalar Dumux::SolidSystems::InertSolidPhase< Scalar, ComponentT >::density ( Scalar  temperature )

inlinestatic

The density \(\mathrm{[kg/m^3]}\) of the solid phase at a given pressure and temperature.

heatCapacity() [1/2]

template<class Scalar , class ComponentT >

template<class SolidState >

static Scalar Dumux::SolidSystems::InertSolidPhase< Scalar, ComponentT >::heatCapacity ( const SolidState &  solidState )

inlinestatic

Specific isobaric heat capacity of the solid \(\mathrm{[J/(kg K)]}\).

heatCapacity() [2/2]

template<class Scalar , class ComponentT >

static Scalar Dumux::SolidSystems::InertSolidPhase< Scalar, ComponentT >::heatCapacity ( Scalar  temperature )

inlinestatic

Specific isobaric heat capacity of the solid \(\mathrm{[J/(kg K)]}\).

isCompressible()

template<class Scalar , class ComponentT >

static constexpr bool Dumux::SolidSystems::InertSolidPhase< Scalar, ComponentT >::isCompressible ( int  compIdx = 0 )

inlinestaticconstexpr

Returns whether the phase is incompressible.

isInert()

template<class Scalar , class ComponentT >

static constexpr bool Dumux::SolidSystems::InertSolidPhase< Scalar, ComponentT >::isInert ( )

inlinestaticconstexpr

Returns whether the component is inert (doesn't react)

molarMass()

template<class Scalar , class ComponentT >

static Scalar Dumux::SolidSystems::InertSolidPhase< Scalar, ComponentT >::molarMass ( int  compIdx = 0 )

inlinestatic

The molar mass in \(\mathrm{[kg/mol]}\) of the component.

name()

template<class Scalar , class ComponentT >

static std::string Dumux::SolidSystems::InertSolidPhase< Scalar, ComponentT >::name ( )

inlinestatic

A human readable name for the solid system.

thermalConductivity() [1/2]

template<class Scalar , class ComponentT >

template<class SolidState >

static Scalar Dumux::SolidSystems::InertSolidPhase< Scalar, ComponentT >::thermalConductivity ( const SolidState &  solidState )

inlinestatic

Thermal conductivity of the solid \(\mathrm{[W/(m K)]}\).

thermalConductivity() [2/2]

template<class Scalar , class ComponentT >

static Scalar Dumux::SolidSystems::InertSolidPhase< Scalar, ComponentT >::thermalConductivity ( Scalar  temperature )

inlinestatic

Thermal conductivity of the solid \(\mathrm{[W/(m K)]}\).

Member Data Documentation

numComponents

template<class Scalar , class ComponentT >

constexpr int Dumux::SolidSystems::InertSolidPhase< Scalar, ComponentT >::numComponents = 1

staticconstexpr

numInertComponents

template<class Scalar , class ComponentT >

constexpr int Dumux::SolidSystems::InertSolidPhase< Scalar, ComponentT >::numInertComponents = 1

staticconstexpr

---

The documentation for this class was generated from the following file:

• inertsolidphase.hh
