Dumux::VTKReader Class Reference

A vtk file reader using tinyxml2 as xml backend. More...

#include <dumux/io/vtk/vtkreader.hh>

Description

A vtk file reader using tinyxml2 as xml backend.

Public Types
enum class	DataType { cellData , pointData }
	The data array types. More...
using	Data = std::unordered_map< std::string, std::vector< double > >
	the cell / point data type for point data read from a grid file More...

Public Member Functions
	VTKReader (const std::string &fileName)
	The contructor creates a tinyxml2::XMLDocument from file. More...
template<class Container >
Container	readData (const std::string &name, const DataType &type) const
	read data from the vtk file to a container, e.g. std::vector<double> More...
template<class Grid >
std::unique_ptr< Grid >	readGrid (bool verbose=false) const
	Read a grid from a vtk/vtu/vtp file, ignoring cell and point data. More...
template<class Grid >
std::unique_ptr< Grid >	readGrid (Dune::GridFactory< Grid > &factory, bool verbose=false) const
	Read a grid from a vtk/vtu/vtp file, ignoring cell and point data. More...
template<class Grid >
std::unique_ptr< Grid >	readGrid (Dune::GridFactory< Grid > &factory, Data &cellData, Data &pointData, bool verbose=false) const
	Read a grid from a vtk/vtu/vtp file, reading all cell and point data. More...

Member Typedef Documentation

Data

using Dumux::VTKReader::Data = std::unordered_map<std::string, std::vector<double> >

the cell / point data type for point data read from a grid file

Member Enumeration Documentation

DataType

enum class Dumux::VTKReader::DataType

strong

The data array types.

Enumerator
cellData
pointData

Constructor & Destructor Documentation

VTKReader()

Dumux::VTKReader::VTKReader ( const std::string &  fileName )

inlineexplicit

The contructor creates a tinyxml2::XMLDocument from file.

Member Function Documentation

readData()

template<class Container >

Container Dumux::VTKReader::readData ( const std::string &  name, const DataType &  type  ) const

inline

read data from the vtk file to a container, e.g. std::vector<double>

Template Parameters

Container

a container type that has begin(), end(), push_back(), e.g. std::vector<>

Parameters

name	the name attribute of the data array to read
type	the data array type

readGrid() [1/3]

template<class Grid >

std::unique_ptr< Grid > Dumux::VTKReader::readGrid ( bool  verbose = false ) const

inline

Read a grid from a vtk/vtu/vtp file, ignoring cell and point data.

Parameters

verbose

if the output should be verbose

readGrid() [2/3]

template<class Grid >

std::unique_ptr< Grid > Dumux::VTKReader::readGrid ( Dune::GridFactory< Grid > &  factory, bool  verbose = false  ) const

inline

Read a grid from a vtk/vtu/vtp file, ignoring cell and point data.

Note

use this signature if the factory might be needed outside to interpret the data via the factory's insertion indices

Parameters

verbose	if the output should be verbose
factory	the (emtpy) grid factory

readGrid() [3/3]

template<class Grid >

std::unique_ptr< Grid > Dumux::VTKReader::readGrid ( Dune::GridFactory< Grid > &  factory, Data &  cellData, Data &  pointData, bool  verbose = false  ) const

inline

Read a grid from a vtk/vtu/vtp file, reading all cell and point data.

Note

the factory will be needed outside to interpret the data via the factory's insertion indices

Parameters

factory	the (emtpy) grid factory
cellData	the cell data arrays to be filled
pointData	the point data arrays to be filled
verbose	if the output should be verbose

---

The documentation for this class was generated from the following file:

• vtkreader.hh
