Dumux::FicksLawImplementation< TypeTag, DiscretizationMethod::cctpfa, referenceSystem > Class Template Reference

Fick's law for cell-centered finite volume schemes with two-point flux approximation. More...

#include <dumux/flux/cctpfa/fickslaw.hh>

Description

template<class TypeTag, ReferenceSystemFormulation referenceSystem>
class Dumux::FicksLawImplementation< TypeTag, DiscretizationMethod::cctpfa, referenceSystem >

Fick's law for cell-centered finite volume schemes with two-point flux approximation.

Public Types
using	Cache = TpfaFicksLawCache
	state the type for the corresponding cache and its filler More...

Static Public Member Functions
static constexpr ReferenceSystemFormulation	referenceSystemFormulation ()
	Return the reference system. More...
static ComponentFluxVector	flux (const Problem &problem, const Element &element, const FVElementGeometry &fvGeometry, const ElementVolumeVariables &elemVolVars, const SubControlVolumeFace &scvf, const int phaseIdx, const ElementFluxVariablesCache &elemFluxVarsCache)
	return diffusive fluxes for all components in a phase More...
static Scalar	calculateTransmissibility (const Problem &problem, const Element &element, const FVElementGeometry &fvGeometry, const ElementVolumeVariables &elemVolVars, const SubControlVolumeFace &scvf, const int phaseIdx, const int compIdx)
	compute diffusive transmissibilities More...

Static Public Attributes
static const DiscretizationMethod	discMethod = DiscretizationMethod::cctpfa
	state the discretization method this implementation belongs to More...

Member Typedef Documentation

Cache

template<class TypeTag , ReferenceSystemFormulation referenceSystem>

using Dumux::FicksLawImplementation< TypeTag, DiscretizationMethod::cctpfa, referenceSystem >::Cache = TpfaFicksLawCache

state the type for the corresponding cache and its filler

Member Function Documentation

calculateTransmissibility()

template<class TypeTag , ReferenceSystemFormulation referenceSystem>

static Scalar Dumux::FicksLawImplementation< TypeTag, DiscretizationMethod::cctpfa, referenceSystem >::calculateTransmissibility ( const Problem &  problem, const Element &  element, const FVElementGeometry &  fvGeometry, const ElementVolumeVariables &  elemVolVars, const SubControlVolumeFace &  scvf, const int  phaseIdx, const int  compIdx  )

inlinestatic

compute diffusive transmissibilities

flux()

template<class TypeTag , ReferenceSystemFormulation referenceSystem>

static ComponentFluxVector Dumux::FicksLawImplementation< TypeTag, DiscretizationMethod::cctpfa, referenceSystem >::flux ( const Problem &  problem, const Element &  element, const FVElementGeometry &  fvGeometry, const ElementVolumeVariables &  elemVolVars, const SubControlVolumeFace &  scvf, const int  phaseIdx, const ElementFluxVariablesCache &  elemFluxVarsCache  )

inlinestatic

return diffusive fluxes for all components in a phase

referenceSystemFormulation()

template<class TypeTag , ReferenceSystemFormulation referenceSystem>

static constexpr ReferenceSystemFormulation Dumux::FicksLawImplementation< TypeTag, DiscretizationMethod::cctpfa, referenceSystem >::referenceSystemFormulation ( )

inlinestaticconstexpr

Return the reference system.

Member Data Documentation

discMethod

template<class TypeTag , ReferenceSystemFormulation referenceSystem>

const DiscretizationMethod Dumux::FicksLawImplementation< TypeTag, DiscretizationMethod::cctpfa, referenceSystem >::discMethod = DiscretizationMethod::cctpfa

static

state the discretization method this implementation belongs to

---

The documentation for this class was generated from the following file:

• cctpfa/fickslaw.hh
