Dumux::EffectiveStressLaw< StressType, GridGeometry, DiscretizationMethod::box > Class Template Reference

Effective stress law for box scheme. More...

#include <dumux/flux/box/effectivestresslaw.hh>

Description

template<class StressType, class GridGeometry>
class Dumux::EffectiveStressLaw< StressType, GridGeometry, DiscretizationMethod::box >

Effective stress law for box scheme.

Template Parameters

StressType	type used for the computation of purely mechanical stresses (i.e. material law)
GridGeometry	the finite volume grid geometry

Public Types
using	Scalar = typename StressType::Scalar
	export the type used for scalar values More...
using	StressTensor = typename StressType::StressTensor
	export the type used for the stress tensor More...
using	ForceVector = typename StressType::ForceVector
	export the type used for force vectors More...

Static Public Member Functions
template<class Problem , class ElementVolumeVariables , class ElementFluxVarsCache >
static ForceVector	force (const Problem &problem, const Element &element, const FVElementGeometry &fvGeometry, const ElementVolumeVariables &elemVolVars, const SubControlVolumeFace &scvf, const ElementFluxVarsCache &elemFluxVarCache)
	computes the force acting on a sub-control volume face More...
template<class Problem , class ElementVolumeVariables , class FluxVarsCache >
static StressTensor	stressTensor (const Problem &problem, const Element &element, const FVElementGeometry &fvGeometry, const ElementVolumeVariables &elemVolVars, const FluxVarsCache &fluxVarsCache)
	assembles the (total) stress tensor of the porous medium at a given integration point More...
template<class Problem , class ElementVolumeVariables , class FluxVarsCache >
static StressTensor	effectiveStressTensor (const Problem &problem, const Element &element, const FVElementGeometry &fvGeometry, const ElementVolumeVariables &elemVolVars, const FluxVarsCache &fluxVarsCache)
	assembles the (effective) stress tensor of the solid skeleton at a given integration point More...

Static Public Attributes
static constexpr DiscretizationMethod	discMethod = DiscretizationMethod::box
	state the discretization method this implementation belongs to More...

Member Typedef Documentation

ForceVector

template<class StressType , class GridGeometry >

using Dumux::EffectiveStressLaw< StressType, GridGeometry, DiscretizationMethod::box >::ForceVector = typename StressType::ForceVector

export the type used for force vectors

Scalar

template<class StressType , class GridGeometry >

using Dumux::EffectiveStressLaw< StressType, GridGeometry, DiscretizationMethod::box >::Scalar = typename StressType::Scalar

export the type used for scalar values

StressTensor

template<class StressType , class GridGeometry >

using Dumux::EffectiveStressLaw< StressType, GridGeometry, DiscretizationMethod::box >::StressTensor = typename StressType::StressTensor

export the type used for the stress tensor

Member Function Documentation

effectiveStressTensor()

template<class StressType , class GridGeometry >

template<class Problem , class ElementVolumeVariables , class FluxVarsCache >

static StressTensor Dumux::EffectiveStressLaw< StressType, GridGeometry, DiscretizationMethod::box >::effectiveStressTensor ( const Problem &  problem, const Element &  element, const FVElementGeometry &  fvGeometry, const ElementVolumeVariables &  elemVolVars, const FluxVarsCache &  fluxVarsCache  )

inlinestatic

assembles the (effective) stress tensor of the solid skeleton at a given integration point

force()

template<class StressType , class GridGeometry >

template<class Problem , class ElementVolumeVariables , class ElementFluxVarsCache >

static ForceVector Dumux::EffectiveStressLaw< StressType, GridGeometry, DiscretizationMethod::box >::force ( const Problem &  problem, const Element &  element, const FVElementGeometry &  fvGeometry, const ElementVolumeVariables &  elemVolVars, const SubControlVolumeFace &  scvf, const ElementFluxVarsCache &  elemFluxVarCache  )

inlinestatic

computes the force acting on a sub-control volume face

stressTensor()

template<class StressType , class GridGeometry >

template<class Problem , class ElementVolumeVariables , class FluxVarsCache >

static StressTensor Dumux::EffectiveStressLaw< StressType, GridGeometry, DiscretizationMethod::box >::stressTensor ( const Problem &  problem, const Element &  element, const FVElementGeometry &  fvGeometry, const ElementVolumeVariables &  elemVolVars, const FluxVarsCache &  fluxVarsCache  )

inlinestatic

assembles the (total) stress tensor of the porous medium at a given integration point

Member Data Documentation

discMethod

template<class StressType , class GridGeometry >

constexpr DiscretizationMethod Dumux::EffectiveStressLaw< StressType, GridGeometry, DiscretizationMethod::box >::discMethod = DiscretizationMethod::box

staticconstexpr

state the discretization method this implementation belongs to

---

The documentation for this class was generated from the following file:

• box/effectivestresslaw.hh
