Provides methods for transmissibility calculation in 3-d. More...

#include <dumux/porousmediumflow/2p/sequential/diffusion/mpfa/lmethod/3dtransmissibilitycalculator.hh>

Description

template<class TypeTag>
class Dumux::FvMpfaL3dTransmissibilityCalculator< TypeTag >

Provides methods for transmissibility calculation in 3-d.

The transmissibilities are calculated using the MPFA L-method.

Aavatsmark et al. 2010 [1]
Wolff et al. 2013 [72]

Various parameters can be defined via an input parameter file or the property system:

MPFAEnableSimpleLStencil - enables the two centered flux stencils MPFAEnableComplexLStencil - enables the two non-centered flux stencils MPFAEnableTPFA - enables the use of TPFA if neighboring cells are of the same grid level MPFATransmissibilityCriterion - 0: Criterion of [1] (default), 1: Criterion of [2]

Public Types
using	TransmissibilityType = Dune::FieldMatrix< Scalar, dim, 2 *dim - dim+1 >
	Type of the transmissibility matrix. More...

Public Member Functions
int	chooseTransmissibility (TransmissibilityType &transmissibilityOne, TransmissibilityType &transmissibilityTwo, int lTypeOne, int lTypeTwo)
	Compares two transmissibility matrices according to a L-selection criterion. More...

int	transmissibility (Dune::FieldMatrix< Scalar, dim, 2 *dim-dim+1 > &transmissibility, InteractionVolume &interactionVolume, std::vector< DimVector > &lambda, int idx1, int idx2, int idx3, int idx4, int idx5, int idx6)

int	transmissibility (Dune::FieldMatrix< Scalar, dim, 2 *dim-dim+1 > &transmissibility, InteractionVolume &interactionVolume, std::vector< DimVector > &lambda, int idx1, int idx2, int idx3, int idx4, int idx5, int idx6, Dune::FieldVector< bool, 4 > &useCases)

int	transmissibilityTPFA (Dune::FieldMatrix< Scalar, dim, 2 *dim-dim+1 > &transmissibility, InteractionVolume &interactionVolume, std::vector< DimVector > &lambda, int idx1, int idx2)
	Calculates a TPFA transmissibility matrix for the flux face between the cells with the local index idx1 and idx2. More...

int	transmissibilityCaseOne (Dune::FieldMatrix< Scalar, dim, 2 *dim-dim+1 > &transmissibility, InteractionVolume &interactionVolume, std::vector< DimVector > &lambda, int idx1, int idx2, int idx3, int idx5)
	Calculates the transmissibility matrix for the flux face between the cells with the local index idx1 and idx2 using the L-shape type 1. More...

int	transmissibilityCaseTwo (Dune::FieldMatrix< Scalar, dim, 2 *dim-dim+1 > &transmissibility, InteractionVolume &interactionVolume, std::vector< DimVector > &lambda, int idx1, int idx2, int idx4, int idx6)
	Calculates the transmissibility matrix for the flux face between the cells with the local index idx1 and idx2 using the L-shape type 2. More...

int	transmissibilityCaseThree (Dune::FieldMatrix< Scalar, dim, 2 *dim-dim+1 > &transmissibility, InteractionVolume &interactionVolume, std::vector< DimVector > &lambda, int idx1, int idx2, int idx4, int idx5)
	Calculates the transmissibility matrix for the flux face between the cells with the local index idx1 and idx2 using the L-shape type 3. More...

int	transmissibilityCaseFour (Dune::FieldMatrix< Scalar, dim, 2 *dim-dim+1 > &transmissibility, InteractionVolume &interactionVolume, std::vector< DimVector > &lambda, int idx1, int idx2, int idx3, int idx6)
	Calculates the transmissibility matrix for the flux face between the cells with the local index idx1 and idx2 using the L-shape type 4. More...

	FvMpfaL3dTransmissibilityCalculator (Problem &problem)
	Constructs a FvMpfaL3dTransmissibilityCalculator object. More...

Member Typedef Documentation

◆ TransmissibilityType

template<class TypeTag >

using Dumux::FvMpfaL3dTransmissibilityCalculator< TypeTag >::TransmissibilityType = Dune::FieldMatrix<Scalar, dim, 2*dim - dim + 1>

Type of the transmissibility matrix.

Constructor & Destructor Documentation

◆ FvMpfaL3dTransmissibilityCalculator()

template<class TypeTag >

Dumux::FvMpfaL3dTransmissibilityCalculator< TypeTag >::FvMpfaL3dTransmissibilityCalculator ( Problem & problem )

inline

Constructs a FvMpfaL3dTransmissibilityCalculator object.

Parameters

problem A problem class object

Member Function Documentation

◆ chooseTransmissibility()

template<class TypeTag >

int Dumux::FvMpfaL3dTransmissibilityCalculator< TypeTag >::chooseTransmissibility	(	TransmissibilityType &	transmissibilityOne,
		TransmissibilityType &	transmissibilityTwo,
		int	lTypeOne,
		int	lTypeTwo
	)

Compares two transmissibility matrices according to a L-selection criterion.

Compares two transmissibility matrices according to the L-selection criterion which is chosen via the parameter/property MPFATransmissibilityCriterion (Criterion of [1], 1: Criterion of [2]) and returns the number of the preferable L-shape (1-4).

Parameters

transmissibilityOne	A first transmissibility matrix
transmissibilityTwo	A second transmissibility matrix
lTypeOne	Type of the L-shape of the first matrix (1-4)
lTypeTwo	Type of the L-shape of the second matrix (1-4)

Returns: The type of the preferable L-shape (1-4)

◆ transmissibility() [1/2]

template<class TypeTag >

int Dumux::FvMpfaL3dTransmissibilityCalculator< TypeTag >::transmissibility	(	Dune::FieldMatrix< Scalar, dim, 2 *dim-dim+1 > &	transmissibility,
		InteractionVolume &	interactionVolume,
		std::vector< DimVector > &	lambda,
		int	idx1,
		int	idx2,
		int	idx3,
		int	idx4,
		int	idx5,
		int	idx6
	)

◆ transmissibility() [2/2]

template<class TypeTag >

int Dumux::FvMpfaL3dTransmissibilityCalculator< TypeTag >::transmissibility	(	Dune::FieldMatrix< Scalar, dim, 2 *dim-dim+1 > &	transmissibility,
		InteractionVolume &	interactionVolume,
		std::vector< DimVector > &	lambda,
		int	idx1,
		int	idx2,
		int	idx3,
		int	idx4,
		int	idx5,
		int	idx6,
		Dune::FieldVector< bool, 4 > &	useCases
	)

◆ transmissibilityCaseFour()

template<class TypeTag >

int Dumux::FvMpfaL3dTransmissibilityCalculator< TypeTag >::transmissibilityCaseFour	(	Dune::FieldMatrix< Scalar, dim, 2 *dim-dim+1 > &	transmissibility,
		InteractionVolume &	interactionVolume,
		std::vector< DimVector > &	lambda,
		int	idx1,
		int	idx2,
		int	idx3,
		int	idx6
	)

Calculates the transmissibility matrix for the flux face between the cells with the local index idx1 and idx2 using the L-shape type 4.

For more details on L-shape type 4 see:

Wolff, 2013 [73]
Wolff et al. 2013 [72]

Parameters

transmissibility	Reference to the local transmissibility matrix
interactionVolume	An interaction volume object
lambda	A vector containing the mobilities of the interaction volume cells in the order of the local interaction volume index
idx1	Local index of cell 1 of 6 cells for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa)
idx2	Local index of cell 2 of 6 cells for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa)
idx3	Local index of cell 3 of 6 cells for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa
idx6	Local index of cell 6 of 6 cells for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa)

Returns: 4 (L-shape 4)

◆ transmissibilityCaseOne()

template<class TypeTag >

int Dumux::FvMpfaL3dTransmissibilityCalculator< TypeTag >::transmissibilityCaseOne	(	Dune::FieldMatrix< Scalar, dim, 2 *dim-dim+1 > &	transmissibility,
		InteractionVolume &	interactionVolume,
		std::vector< DimVector > &	lambda,
		int	idx1,
		int	idx2,
		int	idx3,
		int	idx5
	)

Calculates the transmissibility matrix for the flux face between the cells with the local index idx1 and idx2 using the L-shape type 1.

For more details on L-shape type 1 see:

Wolff, 2013 [73]
Wolff et al. 2013 [72]

Parameters

transmissibility	Reference to the local transmissibility matrix
interactionVolume	An interaction volume object
lambda	A vector containing the mobilities of the interaction volume cells in the order of the local interaction volume index
idx1	Local index of cell 1 of 6 cells for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa)
idx2	Local index of cell 2 of 6 cells for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa)
idx3	Local index of cell 3 of 6 cells for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa
idx5	Local index of cell 5 of 6 cells for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa)

Returns: 1 (L-shape 1)

◆ transmissibilityCaseThree()

template<class TypeTag >

int Dumux::FvMpfaL3dTransmissibilityCalculator< TypeTag >::transmissibilityCaseThree	(	Dune::FieldMatrix< Scalar, dim, 2 *dim-dim+1 > &	transmissibility,
		InteractionVolume &	interactionVolume,
		std::vector< DimVector > &	lambda,
		int	idx1,
		int	idx2,
		int	idx4,
		int	idx5
	)

Calculates the transmissibility matrix for the flux face between the cells with the local index idx1 and idx2 using the L-shape type 3.

For more details on L-shape type 3 see:

Wolff, 2013 [73]
Wolff et al. 2013 [72]

Parameters

transmissibility	Reference to the local transmissibility matrix
interactionVolume	An interaction volume object
lambda	A vector containing the mobilities of the interaction volume cells in the order of the local interaction volume index
idx1	Local index of cell 1 of 6 cells for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa)
idx2	Local index of cell 2 of 6 cells for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa)
idx4	Local index of cell 4 of 6 cells for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa
idx5	Local index of cell 5 of 6 cells for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa)

Returns: 3 (L-shape 3)

◆ transmissibilityCaseTwo()

template<class TypeTag >

int Dumux::FvMpfaL3dTransmissibilityCalculator< TypeTag >::transmissibilityCaseTwo	(	Dune::FieldMatrix< Scalar, dim, 2 *dim-dim+1 > &	transmissibility,
		InteractionVolume &	interactionVolume,
		std::vector< DimVector > &	lambda,
		int	idx1,
		int	idx2,
		int	idx4,
		int	idx6
	)

Calculates the transmissibility matrix for the flux face between the cells with the local index idx1 and idx2 using the L-shape type 2.

For more details on L-shape type 2 see:

Wolff, 2013 [73]
Wolff et al. 2013 [72]

Parameters

transmissibility	Reference to the local transmissibility matrix
interactionVolume	An interaction volume object
lambda	A vector containing the mobilities of the interaction volume cells in the order of the local interaction volume index
idx1	Local index of cell 1 of 6 cells for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa)
idx2	Local index of cell 2 of 6 cells for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa)
idx4	Local index of cell 4 of 6 cells for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa
idx6	Local index of cell 6 of 6 cells for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa)

Returns: 2 (L-shape 2)

◆ transmissibilityTPFA()

template<class TypeTag >

int Dumux::FvMpfaL3dTransmissibilityCalculator< TypeTag >::transmissibilityTPFA	(	Dune::FieldMatrix< Scalar, dim, 2 *dim-dim+1 > &	transmissibility,
		InteractionVolume &	interactionVolume,
		std::vector< DimVector > &	lambda,
		int	idx1,
		int	idx2
	)

Calculates a TPFA transmissibility matrix for the flux face between the cells with the local index idx1 and idx2.

Parameters

transmissibility	Reference to the local transmissibility matrix
interactionVolume	An interaction volume object
lambda	A vector containing the mobilities of the interaction volume cells in the order of the local interaction volume index
idx1	Local index of cell 1 for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa)
idx2	Local index of cell 2 for the calculation of the flux between cell idx1 and idx2 (see doc/docextra/3dmpfa)

The documentation for this class was generated from the following file:

3dtransmissibilitycalculator.hh
