DuMuX: Dumux::CCTpfaGridFluxVariablesCache< P, FVC, FVCF, true, TheTraits > Class Template Reference

3.2-git

DUNE for Multi-{Phase, Component, Scale, Physics, ...} flow and transport in porous media

Flux variable caches on a gridview with grid caching enabled. More...

#include <dumux/discretization/cellcentered/tpfa/gridfluxvariablescache.hh>

Description

template<class P, class FVC, class FVCF, class TheTraits>
class Dumux::CCTpfaGridFluxVariablesCache< P, FVC, FVCF, true, TheTraits >

Flux variable caches on a gridview with grid caching enabled.

Note: The flux caches of the gridview are stored which is memory intensive but faster

Public Types
using	Traits = TheTraits
	the flux variables cache traits More...

using	FluxVariablesCache = typename Traits::FluxVariablesCache
	export the flux variable cache type More...

using	LocalView = typename Traits::template LocalView< ThisType, cachingEnabled >
	export the type of the local view More...

Public Member Functions
	CCTpfaGridFluxVariablesCache (const Problem &problem)

template<class GridGeometry , class GridVolumeVariables , class SolutionVector >
void	update (const GridGeometry &gridGeometry, const GridVolumeVariables &gridVolVars, const SolutionVector &sol, bool forceUpdate=false)

template<class FVElementGeometry , class ElementVolumeVariables >
void	updateElement (const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &element, const FVElementGeometry &fvGeometry, const ElementVolumeVariables &elemVolVars)

template<class SubControlVolumeFace >
const FluxVariablesCache &	operator[] (const SubControlVolumeFace &scvf) const

template<class SubControlVolumeFace >
FluxVariablesCache &	operator[] (const SubControlVolumeFace &scvf)

const Problem &	problem () const

Static Public Attributes
static constexpr bool	cachingEnabled = true
	make it possible to query if caching is enabled More...

Member Typedef Documentation

◆ FluxVariablesCache

template<class P , class FVC , class FVCF , class TheTraits >

using Dumux::CCTpfaGridFluxVariablesCache< P, FVC, FVCF, true, TheTraits >::FluxVariablesCache = typename Traits::FluxVariablesCache

export the flux variable cache type

◆ LocalView

template<class P , class FVC , class FVCF , class TheTraits >

using Dumux::CCTpfaGridFluxVariablesCache< P, FVC, FVCF, true, TheTraits >::LocalView = typename Traits::template LocalView<ThisType, cachingEnabled>

export the type of the local view

◆ Traits

template<class P , class FVC , class FVCF , class TheTraits >

using Dumux::CCTpfaGridFluxVariablesCache< P, FVC, FVCF, true, TheTraits >::Traits = TheTraits

the flux variables cache traits

Constructor & Destructor Documentation

◆ CCTpfaGridFluxVariablesCache()

template<class P , class FVC , class FVCF , class TheTraits >

Dumux::CCTpfaGridFluxVariablesCache< P, FVC, FVCF, true, TheTraits >::CCTpfaGridFluxVariablesCache ( const Problem & problem )

inline

Member Function Documentation

◆ operator[]() [1/2]

template<class P , class FVC , class FVCF , class TheTraits >

template<class SubControlVolumeFace >

FluxVariablesCache & Dumux::CCTpfaGridFluxVariablesCache< P, FVC, FVCF, true, TheTraits >::operator[] ( const SubControlVolumeFace & scvf )

inline

◆ operator[]() [2/2]

template<class P , class FVC , class FVCF , class TheTraits >

template<class SubControlVolumeFace >

const FluxVariablesCache & Dumux::CCTpfaGridFluxVariablesCache< P, FVC, FVCF, true, TheTraits >::operator[] ( const SubControlVolumeFace & scvf ) const

inline

◆ problem()

template<class P , class FVC , class FVCF , class TheTraits >

const Problem & Dumux::CCTpfaGridFluxVariablesCache< P, FVC, FVCF, true, TheTraits >::problem ( ) const

inline

◆ update()

template<class P , class FVC , class FVCF , class TheTraits >

template<class GridGeometry , class GridVolumeVariables , class SolutionVector >

void Dumux::CCTpfaGridFluxVariablesCache< P, FVC, FVCF, true, TheTraits >::update	(	const GridGeometry &	gridGeometry,
		const GridVolumeVariables &	gridVolVars,
		const SolutionVector &	sol,
		bool	forceUpdate = `false`
	)

inline

◆ updateElement()

template<class P , class FVC , class FVCF , class TheTraits >

template<class FVElementGeometry , class ElementVolumeVariables >

void Dumux::CCTpfaGridFluxVariablesCache< P, FVC, FVCF, true, TheTraits >::updateElement	(	const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &	element,
		const FVElementGeometry &	fvGeometry,
		const ElementVolumeVariables &	elemVolVars
	)

inline

Member Data Documentation

◆ cachingEnabled

template<class P , class FVC , class FVCF , class TheTraits >

constexpr bool Dumux::CCTpfaGridFluxVariablesCache< P, FVC, FVCF, true, TheTraits >::cachingEnabled = true

staticconstexpr

make it possible to query if caching is enabled

The documentation for this class was generated from the following file:

cellcentered/tpfa/gridfluxvariablescache.hh
