Dumux::CCMpfaElementFluxVariablesCache< GFVC, true > Class Template Reference

The flux variables caches for an element with caching enabled. More...

#include <dumux/discretization/cellcentered/mpfa/elementfluxvariablescache.hh>

Description

template<class GFVC>
class Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >

The flux variables caches for an element with caching enabled.

Public Types

using PrimaryInteractionVolume = typename GFVC::PrimaryInteractionVolume
 export the interaction volume types More...

using SecondaryInteractionVolume = typename GFVC::SecondaryInteractionVolume

using PrimaryIvDataHandle = typename GFVC::PrimaryIvDataHandle
 export the data handle types used More...

using SecondaryIvDataHandle = typename GFVC::SecondaryIvDataHandle

using FluxVariablesCache = typename GFVC::FluxVariablesCache
 export the flux variable cache type More...

using GridFluxVariablesCache = GFVC
 export the type of the grid flux variables More...


Public Member Functions

 CCMpfaElementFluxVariablesCache (const GridFluxVariablesCache &global)
 The constructor. More...

template<class FVElementGeometry , class ElementVolumeVariables >
void bindElement (const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &element, const FVElementGeometry &fvGeometry, const ElementVolumeVariables &elemVolVars)
 Bind the flux var caches for scvfs inside the element only. More...

template<class FVElementGeometry , class ElementVolumeVariables >
void bind (const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &element, const FVElementGeometry &fvGeometry, const ElementVolumeVariables &elemVolVars)
 Specialization for the global caching being enabled - do nothing here. More...

template<class FVElementGeometry , class ElementVolumeVariables >
void bindScvf (const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &element, const FVElementGeometry &fvGeometry, const ElementVolumeVariables &elemVolVars, const typename FVElementGeometry::SubControlVolumeFace &scvf)
 Bind the flux var caches for an individual scvf. More...

template<class FVElementGeometry , class ElementVolumeVariables >
void update (const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &element, const FVElementGeometry &fvGeometry, const ElementVolumeVariables &elemVolVars)
 Specialization for the global caching being enabled - do nothing here. More...

template<class SubControlVolumeFace >
const FluxVariablesCacheoperator[] (const SubControlVolumeFace &scvf) const
 access operators in the case of caching More...

template<class SubControlVolumeFace >
const PrimaryInteractionVolumeprimaryInteractionVolume (const SubControlVolumeFace &scvf) const
 access to the interaction volume an scvf is embedded in More...

template<class SubControlVolumeFace >
const PrimaryIvDataHandleprimaryDataHandle (const SubControlVolumeFace &scvf) const
 access to the data handle of an interaction volume an scvf is embedded in More...

template<class SubControlVolumeFace >
const SecondaryInteractionVolumesecondaryInteractionVolume (const SubControlVolumeFace &scvf) const
 access to the interaction volume an scvf is embedded in More...

template<class SubControlVolumeFace >
const SecondaryIvDataHandlesecondaryDataHandle (const SubControlVolumeFace &scvf) const
 access to the data handle of an interaction volume an scvf is embedded in More...

const GridFluxVariablesCachegridFluxVarsCache () const
 The global object we are a restriction of. More...


Static Public Attributes

static constexpr bool cachingEnabled = true
 make it possible to query if caching is enabled More...


Member Typedef Documentation

◆ FluxVariablesCache

template<class GFVC >
using Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::FluxVariablesCache = typename GFVC::FluxVariablesCache

export the flux variable cache type

◆ GridFluxVariablesCache

template<class GFVC >
using Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::GridFluxVariablesCache = GFVC

export the type of the grid flux variables

◆ PrimaryInteractionVolume

template<class GFVC >
using Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::PrimaryInteractionVolume = typename GFVC::PrimaryInteractionVolume

export the interaction volume types

◆ PrimaryIvDataHandle

template<class GFVC >
using Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::PrimaryIvDataHandle = typename GFVC::PrimaryIvDataHandle

export the data handle types used

◆ SecondaryInteractionVolume

template<class GFVC >
using Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::SecondaryInteractionVolume = typename GFVC::SecondaryInteractionVolume

◆ SecondaryIvDataHandle

template<class GFVC >
using Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::SecondaryIvDataHandle = typename GFVC::SecondaryIvDataHandle

Constructor & Destructor Documentation

◆ CCMpfaElementFluxVariablesCache()

template<class GFVC >
Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::CCMpfaElementFluxVariablesCache ( const GridFluxVariablesCache global)
inline

The constructor.

Member Function Documentation

◆ bind()

template<class GFVC >
template<class FVElementGeometry , class ElementVolumeVariables >
void Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::bind ( const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &  element,
const FVElementGeometry &  fvGeometry,
const ElementVolumeVariables &  elemVolVars
)
inline

Specialization for the global caching being enabled - do nothing here.

◆ bindElement()

template<class GFVC >
template<class FVElementGeometry , class ElementVolumeVariables >
void Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::bindElement ( const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &  element,
const FVElementGeometry &  fvGeometry,
const ElementVolumeVariables &  elemVolVars
)
inline

Bind the flux var caches for scvfs inside the element only.

◆ bindScvf()

template<class GFVC >
template<class FVElementGeometry , class ElementVolumeVariables >
void Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::bindScvf ( const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &  element,
const FVElementGeometry &  fvGeometry,
const ElementVolumeVariables &  elemVolVars,
const typename FVElementGeometry::SubControlVolumeFace &  scvf
)
inline

Bind the flux var caches for an individual scvf.

◆ gridFluxVarsCache()

template<class GFVC >
const GridFluxVariablesCache & Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::gridFluxVarsCache ( ) const
inline

The global object we are a restriction of.

◆ operator[]()

template<class GFVC >
template<class SubControlVolumeFace >
const FluxVariablesCache & Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::operator[] ( const SubControlVolumeFace &  scvf) const
inline

access operators in the case of caching

◆ primaryDataHandle()

template<class GFVC >
template<class SubControlVolumeFace >
const PrimaryIvDataHandle & Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::primaryDataHandle ( const SubControlVolumeFace &  scvf) const
inline

access to the data handle of an interaction volume an scvf is embedded in

◆ primaryInteractionVolume()

template<class GFVC >
template<class SubControlVolumeFace >
const PrimaryInteractionVolume & Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::primaryInteractionVolume ( const SubControlVolumeFace &  scvf) const
inline

access to the interaction volume an scvf is embedded in

◆ secondaryDataHandle()

template<class GFVC >
template<class SubControlVolumeFace >
const SecondaryIvDataHandle & Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::secondaryDataHandle ( const SubControlVolumeFace &  scvf) const
inline

access to the data handle of an interaction volume an scvf is embedded in

◆ secondaryInteractionVolume()

template<class GFVC >
template<class SubControlVolumeFace >
const SecondaryInteractionVolume & Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::secondaryInteractionVolume ( const SubControlVolumeFace &  scvf) const
inline

access to the interaction volume an scvf is embedded in

◆ update()

template<class GFVC >
template<class FVElementGeometry , class ElementVolumeVariables >
void Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::update ( const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &  element,
const FVElementGeometry &  fvGeometry,
const ElementVolumeVariables &  elemVolVars
)
inline

Specialization for the global caching being enabled - do nothing here.

Member Data Documentation

◆ cachingEnabled

template<class GFVC >
constexpr bool Dumux::CCMpfaElementFluxVariablesCache< GFVC, true >::cachingEnabled = true
staticconstexpr

make it possible to query if caching is enabled


The documentation for this class was generated from the following file:
