Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 3, 1, 1 > Class Template Reference

A class for segment–segment intersection in 3d space. More...

#include <dumux/common/geometry/geometryintersection.hh>

Description

template<class Geometry1, class Geometry2, class Policy>
class Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 3, 1, 1 >

A class for segment–segment intersection in 3d space.

Public Types
using	ctype = typename Policy::ctype
using	Point = typename Policy::Point
using	Intersection = typename Policy::Intersection

Static Public Member Functions
template<class P = Policy, std::enable_if_t< P::dimIntersection==0, int > = 0>
static bool	intersection (const Geometry1 &geo1, const Geometry2 &geo2, Intersection &intersection)
	Colliding two segments. More...
template<class P = Policy, std::enable_if_t< P::dimIntersection==1, int > = 0>
static bool	intersection (const Geometry1 &geo1, const Geometry2 &geo2, Intersection &intersection)
	Colliding two segments in 3D. More...

Member Typedef Documentation

ctype

template<class Geometry1 , class Geometry2 , class Policy >

using Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 3, 1, 1 >::ctype = typename Policy::ctype

Intersection

template<class Geometry1 , class Geometry2 , class Policy >

using Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 3, 1, 1 >::Intersection = typename Policy::Intersection

Point

template<class Geometry1 , class Geometry2 , class Policy >

using Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 3, 1, 1 >::Point = typename Policy::Point

Member Function Documentation

intersection() [1/2]

template<class Geometry1 , class Geometry2 , class Policy >

template<class P = Policy, std::enable_if_t< P::dimIntersection==0, int > = 0>

static bool Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 3, 1, 1 >::intersection ( const Geometry1 &  geo1, const Geometry2 &  geo2, Intersection &  intersection  )

inlinestatic

Colliding two segments.

Parameters

geo1/geo2	The geometries to intersect
intersection	Container to store corners of intersection segment

Note

this overload is used when segment-like intersections are seeked

Todo:

implement this query

intersection() [2/2]

template<class Geometry1 , class Geometry2 , class Policy >

template<class P = Policy, std::enable_if_t< P::dimIntersection==1, int > = 0>

static bool Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 3, 1, 1 >::intersection ( const Geometry1 &  geo1, const Geometry2 &  geo2, Intersection &  intersection  )

inlinestatic

Colliding two segments in 3D.

Parameters

geo1/geo2	The geometries to intersect
intersection	If the geometries collide, is holds the corner points of the intersection object in global coordinates.

Note

This overload is used when segment-like intersections are seeked

---

The documentation for this class was generated from the following file:

• geometryintersection.hh
