Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 3, 3, 2 > Class Template Reference

A class for polyhedron–polygon intersection in 3d space. More...

#include <dumux/common/geometry/geometryintersection.hh>

Description

template<class Geometry1, class Geometry2, class Policy>
class Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 3, 3, 2 >

A class for polyhedron–polygon intersection in 3d space.

Public Types
using	ctype = typename Policy::ctype
using	Point = typename Policy::Point
using	Intersection = typename Policy::Intersection

Static Public Member Functions
template<class P = Policy, std::enable_if_t< P::dimIntersection==2, int > = 0>
static bool	intersection (const Geometry1 &geo1, const Geometry2 &geo2, Intersection &intersection)
	Colliding polygon and convex polyhedron. More...
template<class P = Policy, std::enable_if_t< P::dimIntersection !=2, int > = 0>
static bool	intersection (const Geometry1 &geo1, const Geometry2 &geo2, Intersection &intersection)
	Colliding segment and convex polyhedron. More...

Member Typedef Documentation

ctype

template<class Geometry1 , class Geometry2 , class Policy >

using Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 3, 3, 2 >::ctype = typename Policy::ctype

Intersection

template<class Geometry1 , class Geometry2 , class Policy >

using Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 3, 3, 2 >::Intersection = typename Policy::Intersection

Point

template<class Geometry1 , class Geometry2 , class Policy >

using Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 3, 3, 2 >::Point = typename Policy::Point

Member Function Documentation

intersection() [1/2]

template<class Geometry1 , class Geometry2 , class Policy >

template<class P = Policy, std::enable_if_t< P::dimIntersection==2, int > = 0>

static bool Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 3, 3, 2 >::intersection ( const Geometry1 &  geo1, const Geometry2 &  geo2, Intersection &  intersection  )

inlinestatic

Colliding polygon and convex polyhedron.

Note

First we find the vertex candidates for the intersection region as follows: Add triangle vertices that are inside the tetrahedron Add tetrahedron vertices that are inside the triangle Add all intersection points of tetrahedron edges (codim 2) with the triangle (codim 0) (6*1 tests) Add all intersection points of triangle edges (codim 1) with tetrahedron faces (codim 1) (3*4 tests) Remove duplicate points from the list Compute the convex hull polygon Return a triangulation of that polygon as intersection

Parameters

geo1/geo2	The geometries to intersect
intersection	Container to store the corner points of the polygon (as convex hull)

Note

This overload is used when polygon like intersections are seeked

intersection() [2/2]

template<class Geometry1 , class Geometry2 , class Policy >

template<class P = Policy, std::enable_if_t< P::dimIntersection !=2, int > = 0>

static bool Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 3, 3, 2 >::intersection ( const Geometry1 &  geo1, const Geometry2 &  geo2, Intersection &  intersection  )

inlinestatic

Colliding segment and convex polyhedron.

Note

First we find the vertex candidates for the intersection region as follows: Add triangle vertices that are inside the tetrahedron Add tetrahedron vertices that are inside the triangle Add all intersection points of tetrahedron edges (codim 2) with the triangle (codim 0) (6*1 tests) Add all intersection points of triangle edges (codim 1) with tetrahedron faces (codim 1) (3*4 tests) Remove duplicate points from the list Compute the convex hull polygon Return a triangulation of that polygon as intersection

Parameters

geo1/geo2	The geometries to intersect
intersection	Container to store the intersection result

Todo:

implement overloads for segment or point-like intersections

---

The documentation for this class was generated from the following file:

• geometryintersection.hh
