Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 2, 2, 2 > Class Template Reference

A class for polygon–polygon intersection in 2d space. More...

#include <dumux/common/geometry/geometryintersection.hh>

Description

template<class Geometry1, class Geometry2, class Policy>
class Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 2, 2, 2 >

A class for polygon–polygon intersection in 2d space.

Public Types
using	ctype = typename Policy::ctype
using	Point = typename Policy::Point
using	Intersection = typename Policy::Intersection

Static Public Member Functions
template<class P = Policy, std::enable_if_t< P::dimIntersection==2, int > = 0>
static bool	intersection (const Geometry1 &geo1, const Geometry2 &geo2, Intersection &intersection)
	Colliding two polygons. More...
template<class P = Policy, std::enable_if_t< P::dimIntersection==1, int > = 0>
static bool	intersection (const Geometry1 &geo1, const Geometry2 &geo2, Intersection &intersection)
	Colliding two polygons. More...
template<class P = Policy, std::enable_if_t< P::dimIntersection==0, int > = 0>
static bool	intersection (const Geometry1 &geo1, const Geometry2 &geo2, Intersection &intersection)
	Colliding two polygons. More...

Member Typedef Documentation

ctype

template<class Geometry1 , class Geometry2 , class Policy >

using Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 2, 2, 2 >::ctype = typename Policy::ctype

Intersection

template<class Geometry1 , class Geometry2 , class Policy >

using Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 2, 2, 2 >::Intersection = typename Policy::Intersection

Point

template<class Geometry1 , class Geometry2 , class Policy >

using Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 2, 2, 2 >::Point = typename Policy::Point

Member Function Documentation

intersection() [1/3]

template<class Geometry1 , class Geometry2 , class Policy >

template<class P = Policy, std::enable_if_t< P::dimIntersection==2, int > = 0>

static bool Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 2, 2, 2 >::intersection ( const Geometry1 &  geo1, const Geometry2 &  geo2, Intersection &  intersection  )

inlinestatic

Colliding two polygons.

Note

First we find the vertex candidates for the intersection region as follows: Add polygon vertices that are inside the other polygon Add intersections of polygon edges Remove duplicate points from the list Compute the convex hull polygon Return a triangulation of that polygon as intersection

Parameters

geo1/geo2	The geometries to intersect
intersection	Container to store the corner points of the polygon (as convex hull)

Note

This overload is used when polygon like intersections are seeked

intersection() [2/3]

template<class Geometry1 , class Geometry2 , class Policy >

template<class P = Policy, std::enable_if_t< P::dimIntersection==1, int > = 0>

static bool Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 2, 2, 2 >::intersection ( const Geometry1 &  geo1, const Geometry2 &  geo2, Intersection &  intersection  )

inlinestatic

Colliding two polygons.

Parameters

geo1/geo2	The geometries to intersect
intersection	Container to store the corners of intersection segment

Note

this overload is used when segment-like intersections are seeked

Todo:

implement this query

intersection() [3/3]

template<class Geometry1 , class Geometry2 , class Policy >

template<class P = Policy, std::enable_if_t< P::dimIntersection==0, int > = 0>

static bool Dumux::GeometryIntersection< Geometry1, Geometry2, Policy, 2, 2, 2 >::intersection ( const Geometry1 &  geo1, const Geometry2 &  geo2, Intersection &  intersection  )

inlinestatic

Colliding two polygons.

Parameters

geo1/geo2	The geometries to intersect
intersection	The intersection point

Note

this overload is used when point-like intersections are seeked

Todo:

implement this query

---

The documentation for this class was generated from the following file:

• geometryintersection.hh
