Dumux::PorousMediumFluxVariablesCacheFillerImplementation< TypeTag, DiscretizationMethod::ccmpfa > Class Template Reference

Specialization of the flux variables cache filler for the cell centered mpfa method. More...

#include <dumux/porousmediumflow/fluxvariablescachefiller.hh>

Description

template<class TypeTag>
class Dumux::PorousMediumFluxVariablesCacheFillerImplementation< TypeTag, DiscretizationMethod::ccmpfa >

Specialization of the flux variables cache filler for the cell centered mpfa method.

Public Member Functions
	PorousMediumFluxVariablesCacheFillerImplementation (const Problem &problem)
	The constructor. Sets problem pointer. More...
template<class FluxVarsCacheStorage , class FluxVariablesCache , class IVDataStorage >
void	fill (FluxVarsCacheStorage &fluxVarsCacheStorage, FluxVariablesCache &scvfFluxVarsCache, IVDataStorage &ivDataStorage, const Element &element, const FVElementGeometry &fvGeometry, const ElementVolumeVariables &elemVolVars, const SubControlVolumeFace &scvf, bool forceUpdateAll=false)
	function to fill the flux variables caches More...
const PrimaryInteractionVolume &	primaryInteractionVolume () const
	returns the stored interaction volume pointer More...
const SecondaryInteractionVolume &	secondaryInteractionVolume () const
	returns the stored interaction volume pointer More...
const PrimaryDataHandle &	primaryIvDataHandle () const
	returns the stored data handle pointer More...
const SecondaryDataHandle &	secondaryIvDataHandle () const
	returns the stored data handle pointer More...
const PrimaryLocalFaceData &	primaryIvLocalFaceData () const
	returns the currently stored iv-local face data object More...
const SecondaryLocalFaceData &	secondaryIvLocalFaceData () const
	returns the currently stored iv-local face data object More...

Static Public Attributes
static constexpr bool	isSolDependent = true

Constructor & Destructor Documentation

PorousMediumFluxVariablesCacheFillerImplementation()

template<class TypeTag >

Dumux::PorousMediumFluxVariablesCacheFillerImplementation< TypeTag, DiscretizationMethod::ccmpfa >::PorousMediumFluxVariablesCacheFillerImplementation ( const Problem &  problem )

inline

The constructor. Sets problem pointer.

Member Function Documentation

fill()

template<class TypeTag >

template<class FluxVarsCacheStorage , class FluxVariablesCache , class IVDataStorage >

void Dumux::PorousMediumFluxVariablesCacheFillerImplementation< TypeTag, DiscretizationMethod::ccmpfa >::fill ( FluxVarsCacheStorage &  fluxVarsCacheStorage, FluxVariablesCache &  scvfFluxVarsCache, IVDataStorage &  ivDataStorage, const Element &  element, const FVElementGeometry &  fvGeometry, const ElementVolumeVariables &  elemVolVars, const SubControlVolumeFace &  scvf, bool  forceUpdateAll = false  )

inline

function to fill the flux variables caches

Parameters

fluxVarsCacheStorage	Class that holds the scvf flux vars caches
scvfFluxVarsCache	The flux var cache to be updated corresponding to the given scvf
ivDataStorage	Class that stores the interaction volumes & handles
element	The finite element
fvGeometry	The finite volume geometry
elemVolVars	The element volume variables (primary/secondary variables)
scvf	The corresponding sub-control volume face
forceUpdateAll	if true, forces all caches to be updated (even the solution-independent ones)

primaryInteractionVolume()

template<class TypeTag >

const PrimaryInteractionVolume & Dumux::PorousMediumFluxVariablesCacheFillerImplementation< TypeTag, DiscretizationMethod::ccmpfa >::primaryInteractionVolume ( ) const

inline

returns the stored interaction volume pointer

primaryIvDataHandle()

template<class TypeTag >

const PrimaryDataHandle & Dumux::PorousMediumFluxVariablesCacheFillerImplementation< TypeTag, DiscretizationMethod::ccmpfa >::primaryIvDataHandle ( ) const

inline

returns the stored data handle pointer

primaryIvLocalFaceData()

template<class TypeTag >

const PrimaryLocalFaceData & Dumux::PorousMediumFluxVariablesCacheFillerImplementation< TypeTag, DiscretizationMethod::ccmpfa >::primaryIvLocalFaceData ( ) const

inline

returns the currently stored iv-local face data object

secondaryInteractionVolume()

template<class TypeTag >

const SecondaryInteractionVolume & Dumux::PorousMediumFluxVariablesCacheFillerImplementation< TypeTag, DiscretizationMethod::ccmpfa >::secondaryInteractionVolume ( ) const

inline

returns the stored interaction volume pointer

secondaryIvDataHandle()

template<class TypeTag >

const SecondaryDataHandle & Dumux::PorousMediumFluxVariablesCacheFillerImplementation< TypeTag, DiscretizationMethod::ccmpfa >::secondaryIvDataHandle ( ) const

inline

returns the stored data handle pointer

secondaryIvLocalFaceData()

template<class TypeTag >

const SecondaryLocalFaceData & Dumux::PorousMediumFluxVariablesCacheFillerImplementation< TypeTag, DiscretizationMethod::ccmpfa >::secondaryIvLocalFaceData ( ) const

inline

returns the currently stored iv-local face data object

Member Data Documentation

isSolDependent

template<class TypeTag >

constexpr bool Dumux::PorousMediumFluxVariablesCacheFillerImplementation< TypeTag, DiscretizationMethod::ccmpfa >::isSolDependent = true

staticconstexpr

This cache filler is always solution-dependent, as it updates the vectors of cell unknowns with which the transmissibilities have to be multiplied in order to obtain the fluxes.

---

The documentation for this class was generated from the following file:

• porousmediumflow/fluxvariablescachefiller.hh
