Determines the pressures and saturations of all fluid phases given the total mass of all components. More...

#include <dumux/material/constraintsolvers/immiscibleflash.hh>

Description

template<class Scalar, class FluidSystem>
class Dumux::ImmiscibleFlash< Scalar, FluidSystem >

Determines the pressures and saturations of all fluid phases given the total mass of all components.

In a N-phase, N-component context, we have the following unknowns if assuming immiscibility:

N pressures
N saturations

This sums up to 2*N unknowns. On the equations side of things, we have:

N total component molarities
1 The sum of all saturations is 1
N-1 Relations from capillary pressure

this also sums up to 2*N. We include the capillary pressures and the sum of the saturations explicitly. This means that we only solve for the first pressure and N-1 saturations.

If a fluid phase is incompressible, the pressure cannot determined by this, though. In this case the original pressure is kept, and the saturation of the phase is calculated by dividing the global molarity of the component by the phase density.

Public Types
using	ComponentVector = Dune::FieldVector< Scalar, numComponents >

Public Member Functions
	ImmiscibleFlash (int wettingPhaseIdx=0)
	Contruct a new flash. More...

template<class FluidState >
void	guessInitial (FluidState &fluidState, ParameterCache &paramCache, const ComponentVector &globalMolarities)
	Guess initial values for all quantities. More...

template<class MaterialLaw , class FluidState >
void	solve (FluidState &fluidState, ParameterCache &paramCache, const typename MaterialLaw::Params &matParams, const ComponentVector &globalMolarities)
	Calculates the chemical equilibrium from the component fugacities in a phase. More...

Protected Member Functions
template<class FluidState >
void	printFluidState_ (const FluidState &fs)

template<class MaterialLaw , class FluidState >
void	linearize_ (Matrix &J, Vector &b, FluidState &fluidState, ParameterCache &paramCache, const typename MaterialLaw::Params &matParams, const ComponentVector &globalMolarities)

template<class FluidState >
void	calculateDefect_ (Vector &b, const FluidState &fluidStateEval, const FluidState &fluidState, const ComponentVector &globalMolarities)

template<class MaterialLaw , class FluidState >
Scalar	update_ (FluidState &fluidState, ParameterCache &paramCache, const typename MaterialLaw::Params &matParams, const Vector &deltaX)

template<class MaterialLaw , class FluidState >
void	completeFluidState_ (FluidState &fluidState, ParameterCache &paramCache, const typename MaterialLaw::Params &matParams)

bool	isPressureIdx_ (int pvIdx)

bool	isSaturationIdx_ (int pvIdx)

template<class FluidState >
Scalar	getQuantity_ (const FluidState &fs, int pvIdx)

template<class MaterialLaw , class FluidState >
void	setQuantity_ (FluidState &fs, ParameterCache &paramCache, const typename MaterialLaw::Params &matParams, int pvIdx, Scalar value)

template<class FluidState >
void	setQuantityRaw_ (FluidState &fs, int pvIdx, Scalar value)

template<class FluidState >
Scalar	quantityWeight_ (const FluidState &fs, int pvIdx)

Member Typedef Documentation

◆ ComponentVector

template<class Scalar , class FluidSystem >

using Dumux::ImmiscibleFlash< Scalar, FluidSystem >::ComponentVector = Dune::FieldVector<Scalar, numComponents>

Constructor & Destructor Documentation

◆ ImmiscibleFlash()

template<class Scalar , class FluidSystem >

Dumux::ImmiscibleFlash< Scalar, FluidSystem >::ImmiscibleFlash ( int wettingPhaseIdx = 0 )

inlineexplicit

Contruct a new flash.

Parameters

wettingPhaseIdx the phase index of the wetting phase

Member Function Documentation

◆ calculateDefect_()

template<class Scalar , class FluidSystem >

template<class FluidState >

void Dumux::ImmiscibleFlash< Scalar, FluidSystem >::calculateDefect_	(	Vector &	b,
		const FluidState &	fluidStateEval,
		const FluidState &	fluidState,
		const ComponentVector &	globalMolarities
	)

inlineprotected

◆ completeFluidState_()

template<class Scalar , class FluidSystem >

template<class MaterialLaw , class FluidState >

void Dumux::ImmiscibleFlash< Scalar, FluidSystem >::completeFluidState_	(	FluidState &	fluidState,
		ParameterCache &	paramCache,
		const typename MaterialLaw::Params &	matParams
	)

inlineprotected

◆ getQuantity_()

template<class Scalar , class FluidSystem >

template<class FluidState >

Scalar Dumux::ImmiscibleFlash< Scalar, FluidSystem >::getQuantity_	(	const FluidState &	fs,
		int	pvIdx
	)

inlineprotected

◆ guessInitial()

template<class Scalar , class FluidSystem >

template<class FluidState >

void Dumux::ImmiscibleFlash< Scalar, FluidSystem >::guessInitial	(	FluidState &	fluidState,
		ParameterCache &	paramCache,
		const ComponentVector &	globalMolarities
	)

inline

Guess initial values for all quantities.

Parameters

fluidState	Thermodynamic state of the fluids
paramCache	Container for cache parameters
globalMolarities

◆ isPressureIdx_()

template<class Scalar , class FluidSystem >

bool Dumux::ImmiscibleFlash< Scalar, FluidSystem >::isPressureIdx_ ( int pvIdx )

inlineprotected

◆ isSaturationIdx_()

template<class Scalar , class FluidSystem >

bool Dumux::ImmiscibleFlash< Scalar, FluidSystem >::isSaturationIdx_ ( int pvIdx )

inlineprotected

◆ linearize_()

template<class Scalar , class FluidSystem >

template<class MaterialLaw , class FluidState >

void Dumux::ImmiscibleFlash< Scalar, FluidSystem >::linearize_	(	Matrix &	J,
		Vector &	b,
		FluidState &	fluidState,
		ParameterCache &	paramCache,
		const typename MaterialLaw::Params &	matParams,
		const ComponentVector &	globalMolarities
	)

inlineprotected

◆ printFluidState_()

template<class Scalar , class FluidSystem >

template<class FluidState >

void Dumux::ImmiscibleFlash< Scalar, FluidSystem >::printFluidState_ ( const FluidState & fs )

inlineprotected

◆ quantityWeight_()

template<class Scalar , class FluidSystem >

template<class FluidState >

Scalar Dumux::ImmiscibleFlash< Scalar, FluidSystem >::quantityWeight_	(	const FluidState &	fs,
		int	pvIdx
	)

inlineprotected

◆ setQuantity_()

template<class Scalar , class FluidSystem >

template<class MaterialLaw , class FluidState >

void Dumux::ImmiscibleFlash< Scalar, FluidSystem >::setQuantity_	(	FluidState &	fs,
		ParameterCache &	paramCache,
		const typename MaterialLaw::Params &	matParams,
		int	pvIdx,
		Scalar	value
	)

inlineprotected

◆ setQuantityRaw_()

template<class Scalar , class FluidSystem >

template<class FluidState >

void Dumux::ImmiscibleFlash< Scalar, FluidSystem >::setQuantityRaw_	(	FluidState &	fs,
		int	pvIdx,
		Scalar	value
	)

inlineprotected

◆ solve()

template<class Scalar , class FluidSystem >

template<class MaterialLaw , class FluidState >

void Dumux::ImmiscibleFlash< Scalar, FluidSystem >::solve	(	FluidState &	fluidState,
		ParameterCache &	paramCache,
		const typename MaterialLaw::Params &	matParams,
		const ComponentVector &	globalMolarities
	)

inline

Calculates the chemical equilibrium from the component fugacities in a phase.

Parameters

fluidState	Thermodynamic state of the fluids
paramCache	Container for cache parameters
globalMolarities
matParams	The material law object

The phase's fugacities must already be set.

◆ update_()

template<class Scalar , class FluidSystem >

template<class MaterialLaw , class FluidState >

Scalar Dumux::ImmiscibleFlash< Scalar, FluidSystem >::update_	(	FluidState &	fluidState,
		ParameterCache &	paramCache,
		const typename MaterialLaw::Params &	matParams,
		const Vector &	deltaX
	)

inlineprotected

The documentation for this class was generated from the following file:

immiscibleflash.hh
