DuMuX: Dumux::StaggeredGridFluxVariablesCache< P, FVC, FVCF, true, upwindSchemeOrder, TheTraits > Class Template Reference

3.1-git

DUNE for Multi-{Phase, Component, Scale, Physics, ...} flow and transport in porous media

Flux variables cache class for staggered models. Specialization in case of storing the flux cache. More...

#include <dumux/discretization/staggered/gridfluxvariablescache.hh>

Description

template<class P, class FVC, class FVCF, int upwindSchemeOrder, class TheTraits>
class Dumux::StaggeredGridFluxVariablesCache< P, FVC, FVCF, true, upwindSchemeOrder, TheTraits >

Flux variables cache class for staggered models. Specialization in case of storing the flux cache.

Public Types
using	Traits = TheTraits
	the flux var cache traits More...

using	FluxVariablesCache = typename Traits::FluxVariablesCache
	export the flux variable cache type More...

using	Scalar = typename FluxVariablesCache::Scalar

using	LocalView = typename Traits::template LocalView< ThisType, cachingEnabled >
	export the type of the local view More...

Public Member Functions
	StaggeredGridFluxVariablesCache (const Problem &problem, const std::string &paramGroup="")

template<class GridGeometry , class GridVolumeVariables , class SolutionVector >
void	update (const GridGeometry &gridGeometry, const GridVolumeVariables &gridVolVars, const SolutionVector &sol, bool forceUpdate=false)

const StaggeredUpwindMethods< Scalar, upwindSchemeOrder > &	staggeredUpwindMethods () const
	Return the StaggeredUpwindMethods. More...

const Problem &	problem () const

const FluxVariablesCache &	operator[] (std::size_t scvfIdx) const

FluxVariablesCache &	operator[] (std::size_t scvfIdx)

Static Public Attributes
static constexpr bool	useHigherOrder = upwindSchemeOrder > 1

static constexpr bool	cachingEnabled = true
	make it possible to query if caching is enabled More...

Member Typedef Documentation

◆ FluxVariablesCache

template<class P , class FVC , class FVCF , int upwindSchemeOrder, class TheTraits >

using Dumux::StaggeredGridFluxVariablesCache< P, FVC, FVCF, true, upwindSchemeOrder, TheTraits >::FluxVariablesCache = typename Traits::FluxVariablesCache

export the flux variable cache type

◆ LocalView

template<class P , class FVC , class FVCF , int upwindSchemeOrder, class TheTraits >

using Dumux::StaggeredGridFluxVariablesCache< P, FVC, FVCF, true, upwindSchemeOrder, TheTraits >::LocalView = typename Traits::template LocalView<ThisType, cachingEnabled>

export the type of the local view

◆ Scalar

template<class P , class FVC , class FVCF , int upwindSchemeOrder, class TheTraits >

using Dumux::StaggeredGridFluxVariablesCache< P, FVC, FVCF, true, upwindSchemeOrder, TheTraits >::Scalar = typename FluxVariablesCache::Scalar

◆ Traits

template<class P , class FVC , class FVCF , int upwindSchemeOrder, class TheTraits >

using Dumux::StaggeredGridFluxVariablesCache< P, FVC, FVCF, true, upwindSchemeOrder, TheTraits >::Traits = TheTraits

the flux var cache traits

Constructor & Destructor Documentation

◆ StaggeredGridFluxVariablesCache()

template<class P , class FVC , class FVCF , int upwindSchemeOrder, class TheTraits >

Dumux::StaggeredGridFluxVariablesCache< P, FVC, FVCF, true, upwindSchemeOrder, TheTraits >::StaggeredGridFluxVariablesCache	(	const Problem &	problem,
		const std::string &	paramGroup = `""`
	)

inline

Member Function Documentation

◆ operator[]() [1/2]

template<class P , class FVC , class FVCF , int upwindSchemeOrder, class TheTraits >

FluxVariablesCache & Dumux::StaggeredGridFluxVariablesCache< P, FVC, FVCF, true, upwindSchemeOrder, TheTraits >::operator[] ( std::size_t scvfIdx )

inline

◆ operator[]() [2/2]

template<class P , class FVC , class FVCF , int upwindSchemeOrder, class TheTraits >

const FluxVariablesCache & Dumux::StaggeredGridFluxVariablesCache< P, FVC, FVCF, true, upwindSchemeOrder, TheTraits >::operator[] ( std::size_t scvfIdx ) const

inline

◆ problem()

template<class P , class FVC , class FVCF , int upwindSchemeOrder, class TheTraits >

const Problem & Dumux::StaggeredGridFluxVariablesCache< P, FVC, FVCF, true, upwindSchemeOrder, TheTraits >::problem ( ) const

inline

◆ staggeredUpwindMethods()

template<class P , class FVC , class FVCF , int upwindSchemeOrder, class TheTraits >

const StaggeredUpwindMethods< Scalar, upwindSchemeOrder > & Dumux::StaggeredGridFluxVariablesCache< P, FVC, FVCF, true, upwindSchemeOrder, TheTraits >::staggeredUpwindMethods ( ) const

inline

Return the StaggeredUpwindMethods.

◆ update()

template<class P , class FVC , class FVCF , int upwindSchemeOrder, class TheTraits >

template<class GridGeometry , class GridVolumeVariables , class SolutionVector >

void Dumux::StaggeredGridFluxVariablesCache< P, FVC, FVCF, true, upwindSchemeOrder, TheTraits >::update	(	const GridGeometry &	gridGeometry,
		const GridVolumeVariables &	gridVolVars,
		const SolutionVector &	sol,
		bool	forceUpdate = `false`
	)

inline

Member Data Documentation

◆ cachingEnabled

template<class P , class FVC , class FVCF , int upwindSchemeOrder, class TheTraits >

constexpr bool Dumux::StaggeredGridFluxVariablesCache< P, FVC, FVCF, true, upwindSchemeOrder, TheTraits >::cachingEnabled = true

staticconstexpr

make it possible to query if caching is enabled

◆ useHigherOrder

template<class P , class FVC , class FVCF , int upwindSchemeOrder, class TheTraits >

constexpr bool Dumux::StaggeredGridFluxVariablesCache< P, FVC, FVCF, true, upwindSchemeOrder, TheTraits >::useHigherOrder = upwindSchemeOrder > 1

staticconstexpr

The documentation for this class was generated from the following file:

staggered/gridfluxvariablescache.hh
