Dumux::StaggeredGridFaceVariables< P, FV, true, Traits > Class Template Reference

Face variables cache class for staggered models. Specialization in case of storing the face variables. More...

#include <dumux/discretization/staggered/gridfacevariables.hh>

Description

template<class P, class FV, class Traits>
class Dumux::StaggeredGridFaceVariables< P, FV, true, Traits >

Face variables cache class for staggered models. Specialization in case of storing the face variables.

Public Types
using	LocalView = typename Traits::template LocalView< ThisType, cachingEnabled >
	export the type of the local view More...
using	FaceVariables = typename Traits::FaceVariables
	export the type of the face variables More...

Public Member Functions
	StaggeredGridFaceVariables (const Problem &problem)
template<class GridGeometry , class SolutionVector >
void	update (const GridGeometry &gridGeometry, const SolutionVector &faceSol)
	Update all face variables. More...
const FaceVariables &	faceVars (const std::size_t facetIdx) const
FaceVariables &	faceVars (const std::size_t facetIdx)
const Problem &	problem () const

Static Public Attributes
static constexpr bool	cachingEnabled = true
	make it possible to query if caching is enabled More...

Member Typedef Documentation

FaceVariables

template<class P , class FV , class Traits >

using Dumux::StaggeredGridFaceVariables< P, FV, true, Traits >::FaceVariables = typename Traits::FaceVariables

export the type of the face variables

LocalView

template<class P , class FV , class Traits >

using Dumux::StaggeredGridFaceVariables< P, FV, true, Traits >::LocalView = typename Traits::template LocalView<ThisType, cachingEnabled>

export the type of the local view

Constructor & Destructor Documentation

StaggeredGridFaceVariables()

template<class P , class FV , class Traits >

Dumux::StaggeredGridFaceVariables< P, FV, true, Traits >::StaggeredGridFaceVariables ( const Problem &  problem )

inline

Member Function Documentation

faceVars() [1/2]

template<class P , class FV , class Traits >

FaceVariables & Dumux::StaggeredGridFaceVariables< P, FV, true, Traits >::faceVars ( const std::size_t  facetIdx )

inline

faceVars() [2/2]

template<class P , class FV , class Traits >

const FaceVariables & Dumux::StaggeredGridFaceVariables< P, FV, true, Traits >::faceVars ( const std::size_t  facetIdx ) const

inline

problem()

template<class P , class FV , class Traits >

const Problem & Dumux::StaggeredGridFaceVariables< P, FV, true, Traits >::problem ( ) const

inline

update()

template<class P , class FV , class Traits >

template<class GridGeometry , class SolutionVector >

void Dumux::StaggeredGridFaceVariables< P, FV, true, Traits >::update ( const GridGeometry &  gridGeometry, const SolutionVector &  faceSol  )

inline

Update all face variables.

Member Data Documentation

cachingEnabled

template<class P , class FV , class Traits >

constexpr bool Dumux::StaggeredGridFaceVariables< P, FV, true, Traits >::cachingEnabled = true

staticconstexpr

make it possible to query if caching is enabled

---

The documentation for this class was generated from the following file:

• gridfacevariables.hh
