Dumux::StaggeredElementVolumeVariables< GVV, true > Class Template Reference

Class for the element volume variables vector for the staggered model. Specialization in case the volume variables are stored globally. More...

#include <dumux/discretization/staggered/freeflow/elementvolumevariables.hh>

Description

template<class GVV>
class Dumux::StaggeredElementVolumeVariables< GVV, true >

Class for the element volume variables vector for the staggered model. Specialization in case the volume variables are stored globally.

Public Types
using	GridVolumeVariables = GVV
	export type of the grid volume variables More...
using	VolumeVariables = typename GridVolumeVariables::VolumeVariables
	export type of the volume variables More...

Public Member Functions
	StaggeredElementVolumeVariables (const GridVolumeVariables &gridVolVars)
	Constructor. More...
template<class SubControlVolume , typename std::enable_if_t<!std::is_integral< SubControlVolume >::value, int > = 0>
const VolumeVariables &	operator[] (const SubControlVolume &scv) const
	operator for the access with an scv More...
const VolumeVariables &	operator[] (const std::size_t scvIdx) const
template<class FVElementGeometry , class SolutionVector , typename std::enable_if_t< isMultiTypeBlockVector< SolutionVector >{}(), int > = 0>
void	bind (const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &element, const FVElementGeometry &fvGeometry, const SolutionVector &sol)
template<class FVElementGeometry , class SolutionVector , typename std::enable_if_t<!isMultiTypeBlockVector< SolutionVector >{}(), int > = 0>
void	bind (const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &element, const FVElementGeometry &fvGeometry, const SolutionVector &sol)
template<class FVElementGeometry , class SolutionVector >
void	bindElement (const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &element, const FVElementGeometry &fvGeometry, const SolutionVector &sol)
	function to prepare the vol vars within the element More...
const GridVolumeVariables &	gridVolVars () const
	The global volume variables object we are a restriction of. More...

Member Typedef Documentation

GridVolumeVariables

template<class GVV >

using Dumux::StaggeredElementVolumeVariables< GVV, true >::GridVolumeVariables = GVV

export type of the grid volume variables

VolumeVariables

template<class GVV >

using Dumux::StaggeredElementVolumeVariables< GVV, true >::VolumeVariables = typename GridVolumeVariables::VolumeVariables

export type of the volume variables

Constructor & Destructor Documentation

StaggeredElementVolumeVariables()

template<class GVV >

Dumux::StaggeredElementVolumeVariables< GVV, true >::StaggeredElementVolumeVariables ( const GridVolumeVariables &  gridVolVars )

inline

Constructor.

Member Function Documentation

bind() [1/2]

template<class GVV >

template<class FVElementGeometry , class SolutionVector , typename std::enable_if_t< isMultiTypeBlockVector< SolutionVector >{}(), int > = 0>

void Dumux::StaggeredElementVolumeVariables< GVV, true >::bind ( const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &  element, const FVElementGeometry &  fvGeometry, const SolutionVector &  sol  )

inline

Binding of an element, prepares the volume variables within the element stencil called by the local jacobian to prepare element assembly. Specialization callable with MultiTypeBlockVector.

bind() [2/2]

template<class GVV >

template<class FVElementGeometry , class SolutionVector , typename std::enable_if_t<!isMultiTypeBlockVector< SolutionVector >{}(), int > = 0>

void Dumux::StaggeredElementVolumeVariables< GVV, true >::bind ( const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &  element, const FVElementGeometry &  fvGeometry, const SolutionVector &  sol  )

inline

Binding of an element, prepares the volume variables within the element stencil called by the local jacobian to prepare element assembly

bindElement()

template<class GVV >

template<class FVElementGeometry , class SolutionVector >

void Dumux::StaggeredElementVolumeVariables< GVV, true >::bindElement ( const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &  element, const FVElementGeometry &  fvGeometry, const SolutionVector &  sol  )

inline

function to prepare the vol vars within the element

gridVolVars()

template<class GVV >

const GridVolumeVariables & Dumux::StaggeredElementVolumeVariables< GVV, true >::gridVolVars ( ) const

inline

The global volume variables object we are a restriction of.

operator[]() [1/2]

template<class GVV >

const VolumeVariables & Dumux::StaggeredElementVolumeVariables< GVV, true >::operator[] ( const std::size_t  scvIdx ) const

inline

operator for the access with an index needed for Staggered methods for the access to the boundary volume variables

operator[]() [2/2]

template<class GVV >

template<class SubControlVolume , typename std::enable_if_t<!std::is_integral< SubControlVolume >::value, int > = 0>

const VolumeVariables & Dumux::StaggeredElementVolumeVariables< GVV, true >::operator[] ( const SubControlVolume &  scv ) const

inline

operator for the access with an scv

---

The documentation for this class was generated from the following file:

• staggered/freeflow/elementvolumevariables.hh
