Dumux::StaggeredElementFluxVariablesCache< GFVC, true > Class Template Reference

Class for the stencil local flux variables cache for the staggered model. Specialization for the case of storing the fluxvars cache globally. More...

#include <dumux/discretization/staggered/elementfluxvariablescache.hh>

Description

template<class GFVC>
class Dumux::StaggeredElementFluxVariablesCache< GFVC, true >

Class for the stencil local flux variables cache for the staggered model. Specialization for the case of storing the fluxvars cache globally.

Public Types
using	GridFluxVariablesCache = GFVC
	export the type of the grid flux variables cache More...
using	FluxVariablesCache = typename GFVC::FluxVariablesCache
	export the type of the flux variables cache More...

Public Member Functions
	StaggeredElementFluxVariablesCache (const GridFluxVariablesCache &global)
template<class FVElementGeometry , class ElementVolumeVariables >
void	bindElement (const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &element, const FVElementGeometry &fvGeometry, const ElementVolumeVariables &elemVolVars)
	Specialization for the global caching being enabled - do nothing here. More...
template<class FVElementGeometry , class ElementVolumeVariables >
void	bind (const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &element, const FVElementGeometry &fvGeometry, const ElementVolumeVariables &elemVolVars)
	Specialization for the global caching being enabled - do nothing here. More...
template<class FVElementGeometry , class ElementVolumeVariables >
void	bindScvf (const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &element, const FVElementGeometry &fvGeometry, const ElementVolumeVariables &elemVolVars, const typename FVElementGeometry::SubControlVolumeFace &scvf)
	Specialization for the global caching being enabled - do nothing here. More...
template<class FVElementGeometry , class ElementVolumeVariables >
void	update (const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &element, const FVElementGeometry &fvGeometry, const ElementVolumeVariables &elemVolVars)
	Specialization for the global caching being enabled - do nothing here. More...
template<class SubControlVolumeFace >
const FluxVariablesCache &	operator[] (const SubControlVolumeFace &scvf) const
	operators in the case of caching More...
const GridFluxVariablesCache &	gridFluxVarsCache () const
	The global object we are a restriction of. More...

Member Typedef Documentation

FluxVariablesCache

template<class GFVC >

using Dumux::StaggeredElementFluxVariablesCache< GFVC, true >::FluxVariablesCache = typename GFVC::FluxVariablesCache

export the type of the flux variables cache

GridFluxVariablesCache

template<class GFVC >

using Dumux::StaggeredElementFluxVariablesCache< GFVC, true >::GridFluxVariablesCache = GFVC

export the type of the grid flux variables cache

Constructor & Destructor Documentation

StaggeredElementFluxVariablesCache()

template<class GFVC >

Dumux::StaggeredElementFluxVariablesCache< GFVC, true >::StaggeredElementFluxVariablesCache ( const GridFluxVariablesCache &  global )

inline

Member Function Documentation

bind()

template<class GFVC >

template<class FVElementGeometry , class ElementVolumeVariables >

void Dumux::StaggeredElementFluxVariablesCache< GFVC, true >::bind ( const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &  element, const FVElementGeometry &  fvGeometry, const ElementVolumeVariables &  elemVolVars  )

inline

Specialization for the global caching being enabled - do nothing here.

bindElement()

template<class GFVC >

template<class FVElementGeometry , class ElementVolumeVariables >

void Dumux::StaggeredElementFluxVariablesCache< GFVC, true >::bindElement ( const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &  element, const FVElementGeometry &  fvGeometry, const ElementVolumeVariables &  elemVolVars  )

inline

Specialization for the global caching being enabled - do nothing here.

bindScvf()

template<class GFVC >

template<class FVElementGeometry , class ElementVolumeVariables >

void Dumux::StaggeredElementFluxVariablesCache< GFVC, true >::bindScvf ( const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &  element, const FVElementGeometry &  fvGeometry, const ElementVolumeVariables &  elemVolVars, const typename FVElementGeometry::SubControlVolumeFace &  scvf  )

inline

Specialization for the global caching being enabled - do nothing here.

gridFluxVarsCache()

template<class GFVC >

const GridFluxVariablesCache & Dumux::StaggeredElementFluxVariablesCache< GFVC, true >::gridFluxVarsCache ( ) const

inline

The global object we are a restriction of.

operator[]()

template<class GFVC >

template<class SubControlVolumeFace >

const FluxVariablesCache & Dumux::StaggeredElementFluxVariablesCache< GFVC, true >::operator[] ( const SubControlVolumeFace &  scvf ) const

inline

operators in the case of caching

update()

template<class GFVC >

template<class FVElementGeometry , class ElementVolumeVariables >

void Dumux::StaggeredElementFluxVariablesCache< GFVC, true >::update ( const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &  element, const FVElementGeometry &  fvGeometry, const ElementVolumeVariables &  elemVolVars  )

inline

Specialization for the global caching being enabled - do nothing here.

---

The documentation for this class was generated from the following file:

• staggered/elementfluxvariablescache.hh
