Dumux::CCTpfaElementVolumeVariables< GVV, true > Class Template Reference

The local (stencil) volume variables class for cell centered tpfa models with caching. More...

#include <dumux/discretization/cellcentered/tpfa/elementvolumevariables.hh>

Description

template<class GVV>
class Dumux::CCTpfaElementVolumeVariables< GVV, true >

The local (stencil) volume variables class for cell centered tpfa models with caching.

Note

the volume variables are stored for the whole grid view in the corresponding GridVolumeVariables class

Public Types
using	GridVolumeVariables = GVV
	export type of the grid volume variables More...
using	VolumeVariables = typename GridVolumeVariables::VolumeVariables
	export type of the volume variables More...

Public Member Functions
	CCTpfaElementVolumeVariables (const GridVolumeVariables &gridVolVars)
	Constructor. More...
template<class SubControlVolume , typename std::enable_if_t<!std::is_integral< SubControlVolume >::value, int > = 0>
const VolumeVariables &	operator[] (const SubControlVolume &scv) const
	operator for the access with an scv More...
const VolumeVariables &	operator[] (const std::size_t scvIdx) const
	operator for the access with an index More...
template<class FVElementGeometry , class SolutionVector >
void	bind (const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &element, const FVElementGeometry &fvGeometry, const SolutionVector &sol)
	precompute all boundary volume variables in a stencil of an element, the remaining ones are cached More...
template<class FVElementGeometry , class SolutionVector >
void	bindElement (const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &element, const FVElementGeometry &fvGeometry, const SolutionVector &sol)
	precompute the volume variables of an element - do nothing: volVars are cached More...
const GridVolumeVariables &	gridVolVars () const
	The global volume variables object we are a restriction of. More...

Member Typedef Documentation

GridVolumeVariables

template<class GVV >

using Dumux::CCTpfaElementVolumeVariables< GVV, true >::GridVolumeVariables = GVV

export type of the grid volume variables

VolumeVariables

template<class GVV >

using Dumux::CCTpfaElementVolumeVariables< GVV, true >::VolumeVariables = typename GridVolumeVariables::VolumeVariables

export type of the volume variables

Constructor & Destructor Documentation

CCTpfaElementVolumeVariables()

template<class GVV >

Dumux::CCTpfaElementVolumeVariables< GVV, true >::CCTpfaElementVolumeVariables ( const GridVolumeVariables &  gridVolVars )

inline

Constructor.

Member Function Documentation

bind()

template<class GVV >

template<class FVElementGeometry , class SolutionVector >

void Dumux::CCTpfaElementVolumeVariables< GVV, true >::bind ( const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &  element, const FVElementGeometry &  fvGeometry, const SolutionVector &  sol  )

inline

precompute all boundary volume variables in a stencil of an element, the remaining ones are cached

bindElement()

template<class GVV >

template<class FVElementGeometry , class SolutionVector >

void Dumux::CCTpfaElementVolumeVariables< GVV, true >::bindElement ( const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &  element, const FVElementGeometry &  fvGeometry, const SolutionVector &  sol  )

inline

precompute the volume variables of an element - do nothing: volVars are cached

gridVolVars()

template<class GVV >

const GridVolumeVariables & Dumux::CCTpfaElementVolumeVariables< GVV, true >::gridVolVars ( ) const

inline

The global volume variables object we are a restriction of.

operator[]() [1/2]

template<class GVV >

const VolumeVariables & Dumux::CCTpfaElementVolumeVariables< GVV, true >::operator[] ( const std::size_t  scvIdx ) const

inline

operator for the access with an index

operator[]() [2/2]

template<class GVV >

template<class SubControlVolume , typename std::enable_if_t<!std::is_integral< SubControlVolume >::value, int > = 0>

const VolumeVariables & Dumux::CCTpfaElementVolumeVariables< GVV, true >::operator[] ( const SubControlVolume &  scv ) const

inline

operator for the access with an scv

---

The documentation for this class was generated from the following file:

• cellcentered/tpfa/elementvolumevariables.hh
