Dumux::CCMpfaFVElementGeometry< GG, true > Class Template Reference

Stencil-local finite volume geometry (scvs and scvfs) for cell-centered mpfa models Specialization for grid caching enabled. More...

#include <dumux/discretization/cellcentered/mpfa/fvelementgeometry.hh>

Description

template<class GG>
class Dumux::CCMpfaFVElementGeometry< GG, true >

Stencil-local finite volume geometry (scvs and scvfs) for cell-centered mpfa models Specialization for grid caching enabled.

Note

The finite volume geometries are stored in the corresponding FVGridGeometry

Public Types
using	SubControlVolume = typename GG::SubControlVolume
	export type of subcontrol volume More...
using	SubControlVolumeFace = typename GG::SubControlVolumeFace
	export type of subcontrol volume face More...
using	GridGeometry = GG
	export type of finite volume grid geometry More...
using	FVGridGeometry = GridGeometry

Public Member Functions
	CCMpfaFVElementGeometry (const GridGeometry &gridGeometry)
	Constructor. More...
const SubControlVolume &	scv (GridIndexType scvIdx) const
	Get an element sub control volume with a global scv index. More...
const SubControlVolumeFace &	scvf (GridIndexType scvfIdx) const
	Get an element sub control volume face with a global scvf index. More...
const SubControlVolumeFace &	flipScvf (GridIndexType scvfIdx, unsigned int outsideScvIdx=0) const
std::size_t	numScv () const
	number of sub control volumes in this fv element geometry More...
std::size_t	numScvf () const
	number of sub control volumes in this fv element geometry More...
void	bind (const Element &element)
	Binding of an element, called by the local assembler to prepare element assembly. More...
void	bindElement (const Element &element)
	Bind only element-local. More...
const GridGeometry &	fvGridGeometry () const
	The global finite volume geometry we are a restriction of. More...
const GridGeometry &	gridGeometry () const
bool	hasBoundaryScvf () const
	Returns whether one of the geometry's scvfs lies on a boundary. More...

Static Public Attributes
static constexpr std::size_t	maxNumElementScvs = 1
	the maximum number of scvs per element More...
static constexpr std::size_t	maxNumElementScvfs = dim == 3 ? 24 : 8
	the maximum number of scvfs per element (use cubes for maximum) More...

Member Typedef Documentation

FVGridGeometry

template<class GG >

using Dumux::CCMpfaFVElementGeometry< GG, true >::FVGridGeometry = GridGeometry

GridGeometry

template<class GG >

using Dumux::CCMpfaFVElementGeometry< GG, true >::GridGeometry = GG

export type of finite volume grid geometry

SubControlVolume

template<class GG >

using Dumux::CCMpfaFVElementGeometry< GG, true >::SubControlVolume = typename GG::SubControlVolume

export type of subcontrol volume

SubControlVolumeFace

template<class GG >

using Dumux::CCMpfaFVElementGeometry< GG, true >::SubControlVolumeFace = typename GG::SubControlVolumeFace

export type of subcontrol volume face

Constructor & Destructor Documentation

CCMpfaFVElementGeometry()

template<class GG >

Dumux::CCMpfaFVElementGeometry< GG, true >::CCMpfaFVElementGeometry ( const GridGeometry &  gridGeometry )

inline

Constructor.

Member Function Documentation

bind()

template<class GG >

void Dumux::CCMpfaFVElementGeometry< GG, true >::bind ( const Element &  element )

inline

Binding of an element, called by the local assembler to prepare element assembly.

bindElement()

template<class GG >

void Dumux::CCMpfaFVElementGeometry< GG, true >::bindElement ( const Element &  element )

inline

Bind only element-local.

flipScvf()

template<class GG >

const SubControlVolumeFace & Dumux::CCMpfaFVElementGeometry< GG, true >::flipScvf ( GridIndexType  scvfIdx, unsigned int  outsideScvIdx = 0  ) const

inline

Get the scvf on the same face but from the other side Note that e.g. the normals might be different in the case of surface grids

fvGridGeometry()

template<class GG >

const GridGeometry & Dumux::CCMpfaFVElementGeometry< GG, true >::fvGridGeometry ( ) const

inline

The global finite volume geometry we are a restriction of.

gridGeometry()

template<class GG >

const GridGeometry & Dumux::CCMpfaFVElementGeometry< GG, true >::gridGeometry ( ) const

inline

hasBoundaryScvf()

template<class GG >

bool Dumux::CCMpfaFVElementGeometry< GG, true >::hasBoundaryScvf ( ) const

inline

Returns whether one of the geometry's scvfs lies on a boundary.

numScv()

template<class GG >

std::size_t Dumux::CCMpfaFVElementGeometry< GG, true >::numScv ( ) const

inline

number of sub control volumes in this fv element geometry

numScvf()

template<class GG >

std::size_t Dumux::CCMpfaFVElementGeometry< GG, true >::numScvf ( ) const

inline

number of sub control volumes in this fv element geometry

scv()

template<class GG >

const SubControlVolume & Dumux::CCMpfaFVElementGeometry< GG, true >::scv ( GridIndexType  scvIdx ) const

inline

Get an element sub control volume with a global scv index.

scvf()

template<class GG >

const SubControlVolumeFace & Dumux::CCMpfaFVElementGeometry< GG, true >::scvf ( GridIndexType  scvfIdx ) const

inline

Get an element sub control volume face with a global scvf index.

Member Data Documentation

maxNumElementScvfs

template<class GG >

constexpr std::size_t Dumux::CCMpfaFVElementGeometry< GG, true >::maxNumElementScvfs = dim == 3 ? 24 : 8

staticconstexpr

the maximum number of scvfs per element (use cubes for maximum)

maxNumElementScvs

template<class GG >

constexpr std::size_t Dumux::CCMpfaFVElementGeometry< GG, true >::maxNumElementScvs = 1

staticconstexpr

the maximum number of scvs per element

---

The documentation for this class was generated from the following file:

• discretization/cellcentered/mpfa/fvelementgeometry.hh
