Dumux::BoxElementVolumeVariables< GVV, true > Class Template Reference

The local (stencil) volume variables class for box models with caching. More...

#include <dumux/discretization/box/elementvolumevariables.hh>

Description

template<class GVV>
class Dumux::BoxElementVolumeVariables< GVV, true >

The local (stencil) volume variables class for box models with caching.

Note
the volume variables are stored for the whole grid view in the corresponding GridVolumeVariables class

Public Types

using GridVolumeVariables = GVV
 export type of the grid volume variables More...

using VolumeVariables = typename GridVolumeVariables::VolumeVariables
 export type of the volume variables More...


Public Member Functions

 BoxElementVolumeVariables (const GridVolumeVariables &gridVolVars)
 Constructor. More...

const VolumeVariablesoperator[] (std::size_t scvIdx) const

template<class SubControlVolume , typename std::enable_if_t<!std::is_integral< SubControlVolume >::value, int > = 0>
const VolumeVariablesoperator[] (const SubControlVolume &scv) const

template<class FVElementGeometry , class SolutionVector >
void bind (const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &element, const FVElementGeometry &fvGeometry, const SolutionVector &sol)

template<class FVElementGeometry , class SolutionVector >
void bindElement (const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &element, const FVElementGeometry &fvGeometry, const SolutionVector &sol)

const GridVolumeVariablesgridVolVars () const
 The global volume variables object we are a restriction of. More...


Member Typedef Documentation

◆ GridVolumeVariables

template<class GVV >
using Dumux::BoxElementVolumeVariables< GVV, true >::GridVolumeVariables = GVV

export type of the grid volume variables

◆ VolumeVariables

template<class GVV >
using Dumux::BoxElementVolumeVariables< GVV, true >::VolumeVariables = typename GridVolumeVariables::VolumeVariables

export type of the volume variables

Constructor & Destructor Documentation

◆ BoxElementVolumeVariables()

template<class GVV >
Dumux::BoxElementVolumeVariables< GVV, true >::BoxElementVolumeVariables ( const GridVolumeVariables gridVolVars)
inline

Constructor.

Member Function Documentation

◆ bind()

template<class GVV >
template<class FVElementGeometry , class SolutionVector >
void Dumux::BoxElementVolumeVariables< GVV, true >::bind ( const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &  element,
const FVElementGeometry &  fvGeometry,
const SolutionVector &  sol
)
inline

◆ bindElement()

template<class GVV >
template<class FVElementGeometry , class SolutionVector >
void Dumux::BoxElementVolumeVariables< GVV, true >::bindElement ( const typename FVElementGeometry::GridGeometry::GridView::template Codim< 0 >::Entity &  element,
const FVElementGeometry &  fvGeometry,
const SolutionVector &  sol
)
inline

◆ gridVolVars()

template<class GVV >
const GridVolumeVariables & Dumux::BoxElementVolumeVariables< GVV, true >::gridVolVars ( ) const
inline

The global volume variables object we are a restriction of.

◆ operator[]() [1/2]

template<class GVV >
template<class SubControlVolume , typename std::enable_if_t<!std::is_integral< SubControlVolume >::value, int > = 0>
const VolumeVariables & Dumux::BoxElementVolumeVariables< GVV, true >::operator[] ( const SubControlVolume &  scv) const
inline

◆ operator[]() [2/2]

template<class GVV >
const VolumeVariables & Dumux::BoxElementVolumeVariables< GVV, true >::operator[] ( std::size_t  scvIdx) const
inline

The documentation for this class was generated from the following file:
